Fujitsu ASTG09KMCA Design & Technical Manual

-
(
02 - 05
)
-
OUTDOOR UNIT AOTG09-12KMCA OUTDOOR UNIT AOTG09-12KMCA
CAPACITY COMPENSATION RATE FOR PIPE LENGTH 5.
AND HEIGHT DIFFERENCE
MODEL

:AOTG09KMCA
HEATING
Pipe length (m)
57.5101520
Height
difference H
(m)

1
Indoor unit is
higher than
outdoor unit.
15---0.924 0.873
10 - - 0.975 0.924 0.873
7.5 - 1.000 0.975 0.924 0.873
5 1.006 1.000 0.975 0.924 0.873
0 1.006 1.000 0.975 0.924 0.873

2
Indoor unit is
lower than
outdoor unit.
-5 1.001 0.995 0.970 0.919 0.869
-7.5 - 0.993 0.968 0.917 0.866
-10 - - 0.966 0.915 0.864
-15 - - - 0.906 0.856
COOLING
Pipe length (m)
57.5101520
Height
difference H
(m)

1
Indoor unit is
higher than
outdoor unit.
15 - - - 0.931 0.907
10 - - 0.971 0.947 0.922
7.5 - 0.988 0.975 0.950 0.926
5 1.005 0.992 0.979 0.953 0.930
0 1.013 1.000 0.987 0.962 0.937

2
Indoor unit is
lower than
outdoor unit.
-5 1.013 1.000 0.987 0.962 0.937
-7.5 - 1.000 0.987 0.962 0.937
-10 - - 0.987 0.962 0.937
-15 - - - 0.962 0.937
Height difference H

1: Indoor unit is higher than outdoor unit.

2: Indoor unit is lower than outdoor unit.
Indoor unit
Indoor unit
Connection pipe
Outdoor unit
Outdoor unit
Connection pipe
H
H
