WALL MOUNTED TYPE ASTG09-22LV WALL MOUNTED TYPE ASTG09-22LV
HEATING CAPACITY6-2.
MODEL

:ASTG09LV
MODEL

:ASTG12LV
MODEL

: ASTG18LV
MODEL

: ASTG22LV
AFR : Air Flow Rate (m
3
/min)
TC
: Total Capacity (kW)
IP
: Input Power (kW)
AFR 13.5
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
-15 -16 2.59 0.82 2.52 0.84 2.46 0.86 2.40 0.87 2.34 0.89
-10 -11 2.97 0.88 2.90 0.89 2.82 0.91 2.75 0.93 2.68 0.95
-5 -7 3.32 0.91 3.24 0.93 3.16 0.95 3.08 0.97 3.00 0.98
0 -2 3.81 0.95 3.72 0.97 3.63 0.99 3.54 1.01 3.45 1.03
5 3 4.34 0.98 4.23 1.00 4.13 1.02 4.03 1.04 3.92 1.06
7 6 4.64 1.01 4.53 1.03 4.42 1.05 4.31 1.07 4.20 1.09
10 8 4.84 1.02 4.73 1.04 4.61 1.06 4.49 1.09 4.38 1.11
15 10 5.00 1.02 4.88 1.05 4.76 1.07 4.65 1.09 4.53 1.11
AFR 14.3
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
-15 -16 3.60 1.63 3.51 1.66 3.42 1.70 3.34 1.73 3.25 1.76
-10 -11 4.23 1.75 4.13 1.78 4.03 1.82 3.93 1.86 3.82 1.89
-5 -7 4.84 1.81 4.73 1.85 4.61 1.89 4.50 1.93 4.38 1.96
0 -2 5.62 1.81 5.49 1.85 5.36 1.89 5.22 1.93 5.09 1.96
5 3 6.00 1.60 5.86 1.63 5.71 1.67 5.57 1.70 5.43 1.73
7 6 6.43 1.61 6.27 1.64 6.12 1.67 5.97 1.71 5.81 1.74
10 8 6.69 1.61 6.53 1.64 6.37 1.67 6.21 1.71 6.05 1.74
15 10 6.69 1.50 6.53 1.53 6.37 1.56 6.21 1.59 6.05 1.62
AFR 16.0
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
-15 -16 5.04 2.96 4.92 3.02 4.80 3.08 4.68 3.14 4.56 3.21
-10 -11 5.83 2.96 5.69 3.02 5.55 3.09 5.41 3.15 5.27 3.21
-5 -7 6.55 2.96 6.39 3.02 6.24 3.09 6.08 3.15 5.92 3.21
0 -2 6.80 2.41 6.64 2.46 6.47 2.51 6.31 2.56 6.15 2.61
5 3 7.9 8 2 .4 8 7.7 9 2 .5 4 7. 60 2.59 7.41 2. 64 7.2 2 2.69
7 6 8.66 2.51 8.46 2.56 8.25 2.61 8.04 2.67 7.84 2.72
10 8 9.05 2.50 8.84 2.56 8.62 2.61 8.40 2.66 8.19 2.71
15 10 8.56 2.05 8.35 2.09 8.15 2.14 7.95 2.18 7.74 2.22
AFR 16.0
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
-15 -16 5.77 4.00 5.64 4.04 5.50 4.08 5.36 4.08 5.22 4.08
-10 -11 6.62 3.98 6.46 4.02 6.30 4.06 6.14 4.06 5.99 4.06
-5 -7 7.34 3.98 7.17 4.02 6.99 4.06 6.82 4.06 6.64 4.06
0 -2 8.29 3.97 8.10 4.01 7.90 4.06 7.70 4.06 7.50 4.06
5 3 9.00 3.49 8.79 3.53 8.57 3.56 8.36 3.56 8.14 3.56
7 6 9.14 3.02 8.92 3.05 8.70 3.08 8.48 3.08 8.27 3.08
10 8 9.72 3.04 9.49 3.07 9.26 3.10 9.03 3.10 8.80 3.10
15 10 9.23 2.48 9.01 2.51 8.79 2.53 8.57 2.53 8.35 2.53
