WALL MOUNTED TYPE ASTG09-22LV WALL MOUNTED TYPE ASTG09-22LV
SPECIFICATIONS3.
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name ASTG09LVCC ASTG12LVCC ASTG18LVCC ASTG22LVCC
Power source 240V ~ 50Hz
Available voltage range 198V - 264V ~ 50Hz
STAR RATING INDEX 10 STAR standard
Cooling 4.0 3.0 2.0 2.0
Heating 4.5 4.0 3.5 2.5
Capacity
Cooling
Rated
kW 2.5 3.5 5.0 6.3
Btu/h 8,500 11,900 17,100 21,500
Min-Max
kW 0.50 - 3.30 0.90 - 4.00 0.90 - 5.80 0.90 - 7.30
Btu/h 1,700 - 11,300 3,100 - 13,600 3,100 - 19,800 3,100 - 24,900
Heating
Rated
kW 3.4 4.8 6.0 7.2
Btu/h 11,600 16,400 20,400 23,900
Min-Max
kW 0.50 - 4.00 0.90 - 5.60 1.05 - 8.10 1.05 - 8.70
Btu/h 1,700 - 13,600 3,100 - 19,100 3,600 - 27,600 3,600 - 29,700
Input power
Cooling
Rated
kW
0.58 0.92 1.53 1.95
Min-Max 0.25 - 1.24 0.25 - 1.42 0.18 - 2.03 0.18 - 2.75
Heating
Rated 0.73 1.11 1.49 2.03
Min-Max 0.25 - 1.56 0.25 - 2.00 0.17 - 3.19 0.17 - 4.18
Current
Cooling
Rated A
2.8 4.2 6.5 8.2
Heating 3.5 5.0 6.3 8.5
EER Cooling
kW/kW
4.31 3.80 3.27 3.23
COP Heating 4.66 4.32 4.03 3.55
SENSIBLE CAPACITY Cooling kW 1.61 2.27 3.22 4.46
POWER FACTOR
Cooling
%
86 91 98 99
Heating 87 93 99 99
Moisture removal l/h (pints/h) 1.3 (2.3) 1.8 (3.2) 2.6 (4.6) 2.7 (4.8)
Maximum operating
current *1
Cooling
A
6.0 6.5 9.5 11.5
Heating 7.5 9.0 13.5 17.5
Fan
Airflow
rate
Cooling
High
I/s (m
3
/h)
219 (790) 225 (810) 267 (960) 267 (960)
Med 183 (660) 189 (680) 214 (770) 217 (780)
Low 144 (520) 144 (520) 183 (660) 181 (650)
Quiet 97 (350) 100 (360) 150 (540) 147 (530)
Heating
High 225 (810) 239 (860) 267 (960) 267 (960)
Med 189 (680) 197 (710) 225 (810) 228 (820)
Low 150 (540) 150 (540) 194 (700) 197 (710)
Quiet 100 (360) 100 (360) 144 (520) 147 (530)
Type × Q'ty Cross flow fan×1
Motor output W 44
Sound pressure level
Cooling
High
dB (A)
41 42 46 48
Med 36 37 40 42
Low 30 30 35 37
Quiet 21 21 29 32
Heating
High 42 43 46 48
Med 37384242
Low 31 31 38 38
Quiet 22 22 30 32
Heat exchanger type
Dimensions
(H × W × D)
mm
Main : 384×630×20
Sub : 126×630×13.3
Main : 384×630×20
Sub1 : 126×630×13.3
Sub2 : 84×630×13.3
Fin pitch Main : 1.1, Sub : 1.4
Rows × Stages Main : 2×24, Sub : 1×6
Main : 2×24,
Sub1 : 1×6,
Sub2 : 1×4
Pipe type Copper
Fin type Aluminium
Enclosure
Material Polystyrene
Colour
WHITE
Approximate colour of MUNSELL N9.25/
Dimensions
(H × W × D)
Net
mm
293×790×225
Gross 290×840×375
Weight
Net
kg
9.5 10.0
Gross 12.0
Connection
pipe
Size
Liquid
mm
Ø6.35 (Ø1/4 in.)
Gas Ø9.52 (Ø3/8 in.) Ø12.70 (Ø1/2 in.) Ø15.88 (Ø5/8 in.)
Method Flare
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless
Drain hose
Material PP + LLDPE
Size mm Ø13.8(I.D.), Ø15.8 to Ø16.7(O.D.)
International Protection rating IPX0
Note :
Specifications are based on the following conditions.
Cooling : Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB / 24 °CWB.
Heating : Indoor temperature of 20 °CDB / 15 °CWB.and outdoor temperature of 7 °CDB / 6 °CWB.
Pipe length : 7.5 m, Height difference : 0 m. (Outdoor unit - Indoor unit)
The protective function might work when using it outside the temperature range mentioned above.
*1 : The maximum current is the maximum value when the operated within the operation range.
