01 - 01
)
-
WALL MOUNTED TYPE
ASTG09-22LV
WALL MOUNTED TYPE
ASTG09-22LV
FEATURE1.
MODEL
ASTG09LVCC / AOTG09LVCC
ASTG12LVCC / AOTG12LVCC
ASTG18LVCC / AOTG18LVCC
ASTG22LVCC / AOTG22LVCC
FEATURES
Energy Efficiency
MODEL
ASTG09LVCC ASTG12LVCC ASTG18LVCC ASTG22LVCC
STAR RATING
INDEX
Cooling 4.0 3.0 2.0 2.0
Heating 4.5 4.0 3.5 2.5
High efficiency & Compact
Significantly high efficiency is realized by using DC twin rotary compressor, DC inverter control
and DC fan motor technologies. All models achieve new MEPS standard.
High density multiple path heat exchanger
Original technology supporting
energy saving and high power
Cross section of
copper pipes
1,
Copper pipe diameter
5 mm
High density technology
2,
Refrigerant branches
4*
Multiple path technology
*: For 22 type, refrigerant branches 6.
Smooth flow of the refrigerant
(Schematic)
ALL DC
DC fan motor
DC compressor
The two
aspects that
have evolved
Cooling
Heating
3.0 3.5
0
4.0
9000Btu
18000Btu
4.66 (COP)
3.0 3.5
0
4.0
12000Btu
22000Btu
4.32 (COP)
4.31 (EER)
3.80 (EER)
Cooling
Heating
3.0 3.5
0
4.0
4.03 (COP)
3.0 3.5
0
4.0
3.55 (COP)
3.27 (EER)
3.23 (EER)
790
mm
Compact stylish design
for all capacity range
AOTG09LVCC AOTG12LVCC AOTG18LVCC
AOTG22LVCC
