OUTDOOR UNIT
AOTG09-22LV
OUTDOOR UNIT
AOTG09-22LV
SPECIFICATIONS1.
Type INVERTER HEAT PUMP
Model name AOTG09LVCC AOTG12LVCC AOTG18LVCC AOTG22LVCC
Power source 240V ~ 50Hz
Available voltage range 198V - 264V ~ 50Hz
Starting current A 3.5 5.0 6.5 8.5
Fan
Airflow
rate
Cooling
I/s
(m
3
/h)
475 (1,710) 539 (1,940) 654 (2,355) 683 (2,460)
Heating 461 (1,660) 472 (1,700) 654 (2,355) 650 (2,340)
Type × Q'ty Propeller fan×1
Motor output W 23 50 115 115
Sound pressure level
Cooling
dB (A)
47 48 52 55
Heating 47 48 53 56
Sound power level 64 66 69 72
Heat exchanger type
Dimensions
(H × W × D)
mm
504×642×36.4 504×896×36.4 588×881×36.4
Main : 588×881×36.4
Sub : 546×580×18.2
Fin pitch 1.4 1.3 1.45
Rows × Stages 2×24 2×28
Main : 2×28
Sub : 1×26
Pipe type Copper
Fin
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance (Blue fin)
Compressor
Type × Q'ty Rotary×1
Motor output W 500 750 1,000 1,000
Refrigerant
Type R410A
Charge g 850 1,050 1,450 1,550
Refrigerant oil Type POE
Enclosure
Material Steel
Colour
BEIGE
Approximate colour of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
mm
540×660×290 540×790×290 620×790×290 620×790×290
Gross 610×807×395 633×945×395 713×945×395 713×945×395
Weight
Net
kg
25 34 37 40
Gross 28 37 41 43
Connection pipe
Size
Liquid
mm
Ø6.35
Gas Ø9.52 Ø12.70 Ø15.88
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
10 to 46
Heating -15 to 24
International Protection rating IPX4
Note :
Specifications are based on the following conditions.
Cooling : Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB / 24 °CWB.
Heating : Indoor temperature of 20 °CDB / 15 °CWB.and outdoor temperature of 7 °CDB / 6 °CWB.
Pipe length : 7.5 m, Height difference : 0 m.(Outdoor unit - Indoor unit)
* The protective function might work when using it outside the temperature range mentioned above.
