WALL MOUNTED TYPE
ASTG09-22LV
WALL MOUNTED TYPE
ASTG09-22LV
ELECTRIC CHARACTERISTICS9.
Model name ASTG09LV ASTG12LV ASTG18LV ASTG22LV
Power supply
Voltage V 240 ~
Frequency Hz 50
Max. operating current A 0.3
Wiring Spec.
Connection cable mm
2
1.5
Limited wiring length m 21
Note : Wiring Spec.
1. Selected Sample
(Selected based on Japan Electrotechnical Standard and Codes Committee E0005)
2. Limited wiring length: Limit voltage drop to less than 2%. Increase cable gauge if voltage drop is 2% or more.
3. Use conformed cable with Type 60245 IEC57.
To Next Page
