- 15 -
WALL MOUNTED ASU30RLE
 Installation space requirement
Provide sufficient installation space for product safety.
2-1/2 (63)
or more
3-8/1 (80)
or more
1-15/16 (50)
or more
1-15/16 (49)
or more
2-6/16 (60)
or more
Outline of unit
5-1/8 (130)
or more
59-1/16 (1,500) or more
70-7/8 (1,800) or more
Unit: in (mm)
