- 18 -
WALL MOUNTED
ASU30RLE
6-2. Heating capacity
Model: ASU30RLE
AFR CFM 812
Indoor temperature
°FDB 60 65 70 72 75
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-15 -17 24.02 3.80 23.45 3.87 22.88 3.95 22.30 4.02 21.73 4.10
-5 -7 28.62 4.04 27.94 4.12 27.26 4.20 26.57 4.28 25.89 4.36
5 3 33.64 4.37 32.83 4.46 32.03 4.55 31.23 4.64 30.43 4.72
14 12 36.64 4.33 35.77 4.41 34.89 4.50 34.02 4.59 33.15 4.67
23 19 37.59 4.37 36.69 4.46 35.80 4.54 34.90 4.63 34.01 4.72
32 28 39.07 4.27 38.14 4.36 37.21 4.44 36.28 4.53 35.35 4.61
41 37 38.98 3.60 38.05 3.67 37.12 3.75 36.19 3.82 35.26 3.90
47 43 39.09 3.30 38.16 3.36 37.23 3.43 36.29 3.50 35.36 3.57
50 47 39.35 3.20 38.41 3.27 37.47 3.34 36.54 3.40 35.60 3.45
59 50 40.13 2.93 39.17 2.99 38.21 3.05 37.26 3.11 36.30 3.16
AFR
m
3
/h
1,380
Indoor temperature
°CDB 15.6 18.3 21.1 22.2 23.9
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-26.1 -27.2 7.04 3.80 6.87 3.87 6.70 3.95 6.54 4.02 6.37 4.10
-20.6 -21.7 8.39 4.04 8.19 4.12 7.99 4.20 7.79 4.28 7.59 4.36
-15.0 -16.1 9.86 4.37 9.62 4.46 9.39 4.55 9.15 4.64 8.92 4.72
-10.0 -11.1 10.74 4.33 10.48 4.41 10.23 4.50 9.97 4.59 9.72 4.67
-5.0 -7.2 11.02 4.37 10.75 4.46 10.49 4.54 10.23 4.63 9.97 4.72
0.0 -2.2 11.45 4.27 11.18 4.36 10.91 4.44 10.63 4.53 10.36 4.61
5.0 2.8 11.42 3.60 11.15 3.67 10.88 3.75 10.61 3.82 10.34 3.90
8.3 6.1 11.46 3.30 11.18 3.36 10.91 3.43 10.64 3.50 10.36 3.57
10.0 8.3 11.53 3.20 11.26 3.27 10.98 3.34 10.71 3.40 10.43 3.45
15.0 10.0 11.76 2.93 11.48 2.99 11.20 3.05 10.92 3.11 10.64 3.16
