Fujitsu ASU30RLE Design & Technical Manual

- 22 -
WALL MOUNTED ASU30RLE
8. Operation noise (sound pressure)
8-1. Noise level curve
 Model: ASU30RLE
 Cooling  Heating
Octave band sound pressure level, dB: (0 dB=0.0002 μbar)
80
70
60
50
40
30
20
10
0
Octave band center frequency, Hz
63 125 250 500 1,000 2,000 4,000 8,000
NC-20
NC-40
NC-50
NC-60
NC-30
NC-15
NC-25
NC-35
NC-45
NC-55
NC-65
HIGH
QUIET
Octave band sound pressure level, dB: (0 dB=0.0002 μbar)
80
70
60
50
40
30
20
10
0
Octave band center frequency, Hz
63 125 250 500 1,000 2,000 4,000 8,000
NC-20
NC-40
NC-50
NC-60
NC-30
NC-15
NC-25
NC-35
NC-45
NC-55
NC-65
HIGH
QUIET
