- 65 -
OUTDOOR UNIT
AOU30RLXEH
4. Refrigerant circuit
4-1. Model: AOU30RLXEH
SUB
ACM
FAN
4WV
CMP
AC
OUTER
HEX
INNER
HEX
FAN
STRAINER
3WV
3WV
STRAINER
MUFFULER
EEV
SERVICE
PORT
PRESSURE
SENSOR
FUSIBLE
PLUG
STRAINER
