Fujitsu ASU30RLE - Page 24

- 20 -
WALL MOUNTED ASU30RLE
Side view
Vertical airflow direction louver: Down
Horizontal airflow direction louver: Center
3
2
1
0
(m)
(m)
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
2.0
1.5
1.0
0.5
0
Unit: ft/s (m/s)
7
3
10
(ft)
(ft)
10 20 30 40 50
