Outdoor unit: AOU45RLXFZ
No. Unit 1 Unit 2 Unit 3 Unit 4 Unit 5 Total
46 7 7 9 24 — 47
47 7 7 12 12 — 38
48 7 7 12 15 — 41
49 7 7 12 18 — 44
50 7 7 12 24 — 50
51 7 7 15 15 — 44
52 7 7 15 18 — 47
53 7 7 15 24 — 53
54 7 7 18 18 — 50
55 7 9 9 9 — 34
56 7 9 9 12 — 37
57 7 9 9 15 — 40
58 7 9 9 18 — 43
59 7 9 9 24 — 49
60 7 9 12 12 — 40
61 7 9 12 15 — 43
62 7 9 12 18 — 46
63 7 9 12 24 — 52
64 7 9 15 15 — 46
65 7 9 15 18 — 49
66 7 9 18 18 — 52
67 7 12 12 12 — 43
68 7 12 12 15 — 46
69 7 12 12 18 — 49
70 7 12 15 15 — 49
71 7 12 15 18 — 52
72 7 15 15 15 — 52
73 9 9 9 9 — 36
74 9 9 9 12 — 39
75 9 9 9 15 — 42
76 9 9 9 18 — 45
77 9 9 9 24 — 51
78 9 9 12 12 — 42
79 9 9 12 15 — 45
80 9 9 12 18 — 48
81 9 9 12 24 — 54
82 9 9 15 15 — 48
83 9 9 15 18 — 51
84 9 9 18 18 — 54
85 9 12 12 12 — 45
86 9 12 12 15 — 48
87 9 12 12 18 — 51
88 9 12 15 15 — 51
89 9 12 15 18 — 54
90 12 12 12 12 — 48
91 12 12 12 15 — 51
92 12 12 12 18 — 54
93 12 12 12 18 — 54
94 12 12 15 15 — 54
95 7 7 7 7 7 35
96 7 7 7 7 9 37
97 7 7 7 7 12 40
98 7 7 7 7 15 43
99 7 7 7 7 18 46
100 7 7 7 7 24 52
- 4 -
1-1. Indoor unit connection patterns 1. Model lineup
MULTI-SPLIT TYPE 5-unit type MULTI-SPLIT TYPE 5-unit type
