16-2. Slim duct type indoor unit (setting by DIP switch)
By using some components on the PCB, you can change the function settings.
Related components on the PCB and the applicable settings:
Component Setting content
DIP switch SW101
1 Drainage function setting
2 Auto louver grille setting
3 Fan delay setting
¢ Component location
Components on the indoor unit main PCB used for the function settings are located as shown in
the following figure.
SW101
1
2
3
- 185 -
16-2. Slim duct type indoor unit (setting by DIP switch) 16. Function settings
MULTI-SPLIT TYPE 5-unit type MULTI-SPLIT TYPE 5-unit type
