2-4. Wall mounted type (ASUH07-15LPAS)
Model name ASUH07LPAS ASUH09LPAS ASUH12LPAS ASUH15LPAS
Power supply 208/230 V ~ 60 Hz
Available voltage range 187—264 V
Capacity Btu/h class 7,000 9,000 12,000 14,000
Input power W 18 22 26 42
Running current A 0.18 0.20 0.24 0.35
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
383 (650) 412 (700) 412 (700) 453 (770)
MED 318 (540) 330 (560) 330 (560) 353 (600)
LOW 253 (430) 253 (430) 253 (430) 265 (450)
QUIET 188 (320) 188 (320) 182 (310) 182 (310)
Heating
HIGH 424 (720) 441 (750) 453 (770) 483 (820)
MED 341 (580) 359 (610) 377 (640) 388 (660)
LOW 271 (460) 277 (470) 306 (520) 306 (520)
QUIET 194 (330) 194 (330) 182 (310) 200 (340)
Type × Qty Crossflow fan × 1
Motor output W 49
Sound pressure level*1
Cooling
HIGH
dB (A)
38 40 43
MED 33 34 35 36
LOW 29 30
QUIET 21
Heating
HIGH 41 42 44
MED 35 36 38 39
LOW 31 33
QUIET 22 24
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main1: 8-1/4 × 26-5/16 × 1-1/16
(210 × 668 × 26.6)
Main2: 4-7/16 × 26-5/16 × 13/16
(112 × 668 × 20)
Main1: 8-1/4 × 26-5/16 × 1-1/16
(210 × 668 × 26.6)
Main2: 4-7/16 × 26-5/16 × 13/16
(112 × 668 × 20)
Sub: 3-5/16 × 26-5/16 × 1/2
(84 × 668 × 13.3)
Fin pitch FPI
Man1: 21
Main2: 23
Man1: 21
Main2: 23
Sub: 18
Rows × Stages
Main1: 2 × 10
Main2: 2 × 7
Main1: 2 × 10
Main2: 2 × 7
Sub: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in (mm)
10-5/8 × 32-13/16 × 8-3/4 (270 × 834 × 222)
Gross 10-7/8 × 36 × 13-1/16 (277 × 914 × 332)
Weight
Net
lb (kg)
21 (9.5) 22 (10.0)
Gross 26 (12.0) 29 (13.0)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52) Ø1/2 (Ø12.7)
Method Flare
Drain hose
Material PP+HDPE
Tip diameter in (mm) Ø17/32 (Ø13.8) (I.D.), Ø19/32 to 21/32 (Ø15.0 to 16.8) (O.D.)
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 86 (16 to 30)
Remote controller type
Wireless (Wired, Mobile app*2 [FGLair
™
] [option])
NOTES:
• The protective function might work when using it outside the operation range.
• *1: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *2: Available on Google Play
™
store or on App Store
®
. Optional WLAN Adapter is also required. For details, refer to the setting manual.
- 10 -
2-4. Wall mounted type (ASUH07-15LPAS) 2. Specifications
MULTI-SPLIT TYPE 5-unit type
MULTI-SPLIT TYPE 5-unit type

Fujitsu ASUH07LPAS Specifications

General

Brand	Fujitsu
Model	ASUH07LPAS
Category	Air Conditioner
Language	English
