¢ Slim duct type
 Unit: kBtu/h, °F
• TC: Total Capacity (kBtu/h), SHC: Sensible Heat Capacity (kBtu/h).
• The data is based on the following conditions.
• Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: ADUH07LUAS1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
23.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
32.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
41.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
50.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
59.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
67.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
77.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
87.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
95.0 5.88 4.07 6.65 4.64 7.01 5.34 7.50 6.00 8.02 6.56 8.27 7.52
104.0 5.56 3.64 6.29 4.15 6.63 4.78 7.10 5.37 7.59 5.88 7.82 6.73
115.0 5.25 3.24 5.93 3.69 6.25 4.25 6.69 4.78 7.15 5.23 7.38 5.99
MODEL: ADUH09LUAS1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
23.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
32.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
41.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
50.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
59.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
67.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
77.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
87.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
95.0 7.53 4.82 8.51 5.49 8.97 6.32 9.60 7.10 10.26 7.77 10.58 8.90
104.0 7.12 4.31 8.05 4.92 8.48 5.66 9.08 6.36 9.71 6.96 10.01 7.97
115.0 6.72 3.84 7.59 4.37 8.00 5.04 8.57 5.66 9.16 6.19 9.44 7.09
MODEL: ADUH12LUAS1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
23.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
32.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
41.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
50.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
59.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
67.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
77.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
87.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
95.0 9.88 6.32 11.16 7.21 11.77 8.30 12.60 9.32 13.47 10.20 13.89 11.68
104.0 9.35 5.66 10.56 6.45 11.14 7.43 11.92 8.35 12.74 9.13 13.14 10.46
115.0 8.82 5.04 9.96 5.74 10.50 6.61 11.24 7.42 12.02 8.12 12.39 9.30
- 262 -
6-2. Cooling capacity 6. Capacity table
