Combination of indoor unit
Type of in-
door unit
Rated capacity for each indoor
unit [kBtu/h]
Maximum capacity for each in-
door unit [kBtu/h]
Total capacity
[kBtu/h]
Input power [kW]
Unit
Total
Unit Unit
Min. Rated Max. Min. Rated Max.
1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
7 9 12 24 — 52 Ducted 6.2 8.0 10.6 21.2 — 7.3 9.3 12.5 24.9 — 12.0 46.0 54.0 0.70 3.83 4.41
7 9 18 18 — 52 Ducted 6.2 8.0 15.9 15.9 — 7.3 9.3 18.7 18.7 — 12.0 46.0 54.0 0.70 3.89 4.41
7 12 12 12 — 43 Ducted 7.2 12.3 12.3 12.3 — 8.4 14.4 14.4 14.4 — 12.0 44.0 51.6 0.70 3.79 4.21
7 12 12 18 — 49 Ducted 6.6 11.3 11.3 16.9 — 7.7 13.2 13.2 19.8 — 12.0 46.0 54.0 0.70 3.97 4.41
9 9 9 9 — 36 Ducted 9.2 9.2 9.2 9.2 — 10.8 10.8 10.8 10.8 — 12.0 36.8 43.2 0.70 3.13 3.48
9 9 9 12 — 39 Ducted 9.2 9.2 9.2 12.3 — 10.8 10.8 10.8 14.4 — 12.0 39.9 46.8 0.70 3.34 3.79
9 9 9 18 — 45 Ducted 9.2 9.2 9.2 18.4 — 10.8 10.8 10.8 21.6 — 12.0 46.0 54.0 0.70 3.89 4.41
9 9 9 24 — 51 Ducted 8.1 8.1 8.1 21.6 — 9.5 9.5 9.5 25.4 — 12.0 46.0 54.0 0.70 3.89 4.41
9 9 12 12 — 42 Ducted 9.2 9.2 12.3 12.3 — 10.8 10.8 14.4 14.4 — 12.0 42.9 50.4 0.70 3.61 4.10
9 9 12 18 — 48 Ducted 8.6 8.6 11.5 17.3 — 10.1 10.1 13.5 20.3 — 12.0 46.0 54.0 0.70 3.89 4.41
9 9 12 24 — 54 Ducted 7.7 7.7 10.2 20.4 — 9.0 9.0 12.0 24.0 — 12.0 46.0 54.0 0.70 3.89 4.41
9 9 18 18 — 54 Ducted 7.7 7.7 15.3 15.3 — 9.0 9.0 18.0 18.0 — 12.0 46.0 54.0 0.70 3.97 4.41
9 12 12 12 — 45 Ducted 9.2 12.3 12.3 12.3 — 10.8 14.4 14.4 14.4 — 12.0 46.0 54.0 0.70 3.97 4.41
9 12 12 18 — 51 Ducted 8.1 10.8 10.8 16.2 — 9.5 12.7 12.7 19.1 — 12.0 46.0 54.0 0.70 3.97 4.41
12 12 12 12 — 48 Ducted 11.5 11.5 11.5 11.5 — 13.5 13.5 13.5 13.5 — 12.0 46.0 54.0 0.70 3.89 4.41
12 12 12 18 — 54 Ducted 10.2 10.2 10.2 15.3 — 12.0 12.0 12.0 18.0 — 12.0 46.0 54.0 0.70 3.89 4.41
12 12 12 18 — 54 Ducted 10.2 10.2 10.2 15.3 — 12.0 12.0 12.0 18.0 — 12.0 46.0 54.0 0.70 3.89 4.41
7 7 7 7 7 35 Ducted 7.2 7.2 7.2 7.2 7.2 8.4 8.4 8.4 8.4 8.4 12.0 35.8 42.0 0.70 2.98 3.38
7 7 7 7 9 37 Ducted 7.2 7.2 7.2 7.2 9.2 8.4 8.4 8.4 8.4 10.8 12.0 37.8 44.4 0.70 3.16 3.58
7 7 7 7 12 40 Ducted 7.2 7.2 7.2 7.2 12.3 8.4 8.4 8.4 8.4 14.4 12.0 40.9 48.0 0.70 3.43 3.89
7 7 7 7 18 46 Ducted 7.0 7.0 7.0 7.0 18.0 8.2 8.2 8.2 8.2 21.1 12.0 46.0 54.0 0.70 3.89 4.41
7 7 7 7 24 52 Ducted 6.2 6.2 6.2 6.2 21.2 7.3 7.3 7.3 7.3 24.9 12.0 46.0 54.0 0.70 3.89 4.41
7 7 7 9 9 39 Ducted 7.2 7.2 7.2 9.2 9.2 8.4 8.4 8.4 10.8 10.8 12.0 39.9 46.8 0.70 3.34 3.79
7 7 7 9 12 42 Ducted 7.2 7.2 7.2 9.2 12.3 8.4 8.4 8.4 10.8 14.4 12.0 42.9 50.4 0.70 3.61 4.10
7 7 7 9 18 48 Ducted 6.7 6.7 6.7 8.6 17.3 7.9 7.9 7.9 10.1 20.3 12.0 46.0 54.0 0.70 3.89 4.41
7 7 7 9 24 54 Ducted 6.0 6.0 6.0 7.7 20.4 7.0 7.0 7.0 9.0 24.0 12.0 46.0 54.0 0.70 3.89 4.41
7 7 7 12 12 45 Ducted 7.2 7.2 7.2 12.3 12.3 8.4 8.4 8.4 14.4 14.4 12.0 46.0 54.0 0.70 3.89 4.41
7 7 7 12 18 51 Ducted 6.3 6.3 6.3 10.8 16.2 7.4 7.4 7.4 12.7 19.1 12.0 46.0 54.0 0.70 3.89 4.41
7 7 9 9 9 41 Ducted 7.2 7.2 9.2 9.2 9.2 8.4 8.4 10.8 10.8 10.8 12.0 41.9 49.2 0.70 3.49 4.00
7 7 9 9 12 44 Ducted 7.2 7.2 9.2 9.2 12.3 8.4 8.4 10.8 10.8 14.4 12.0 45.0 52.8 0.70 3.80 4.31
7 7 9 9 18 50 Ducted 6.4 6.4 8.3 8.3 16.6 7.6 7.6 9.7 9.7 19.4 12.0 46.0 54.0 0.70 3.89 4.41
7 7 9 12 12 47 Ducted 6.9 6.9 8.8 11.7 11.7 8.0 8.0 10.3 13.8 13.8 12.0 46.0 54.0 0.70 3.89 4.41
7 7 9 12 18 53 Ducted 6.1 6.1 7.8 10.4 15.6 7.1 7.1 9.2 12.2 18.3 12.0 46.0 54.0 0.70 3.89 4.41
7 7 12 12 12 50 Ducted 6.4 6.4 11.0 11.0 11.0 7.6 7.6 13.0 13.0 13.0 12.0 46.0 54.0 0.70 3.89 4.41
7 9 9 9 9 43 Ducted 7.2 9.2 9.2 9.2 9.2 8.4 10.8 10.8 10.8 10.8 12.0 44.0 51.6 0.70 3.71 4.21
7 9 9 9 12 46 Ducted 7.0 9.0 9.0 9.0 12.0 8.2 10.6 10.6 10.6 14.1 12.0 46.0 54.0 0.70 3.89 4.41
7 9 9 9 18 52 Ducted 6.2 8.0 8.0 8.0 15.9 7.3 9.3 9.3 9.3 18.7 12.0 46.0 54.0 0.70 3.89 4.41
7 9 9 12 12 49 Ducted 6.6 8.4 8.4 11.3 11.3 7.7 9.9 9.9 13.2 13.2 12.0 46.0 54.0 0.70 3.89 4.41
7 9 12 12 12 52 Ducted 6.2 8.0 10.6 10.6 10.6 7.3 9.3 12.5 12.5 12.5 12.0 46.0 54.0 0.70 3.83 4.41
9 9 9 9 9 45 Ducted 9.2 9.2 9.2 9.2 9.2 10.8 10.8 10.8 10.8 10.8 12.0 46.0 54.0 0.70 3.89 4.41
9 9 9 9 12 48 Ducted 8.6 8.6 8.6 8.6 11.5 10.1 10.1 10.1 10.1 13.5 12.0 46.0 54.0 0.70 3.89 4.41
9 9 9 9 18 54 Ducted 7.7 7.7 7.7 7.7 15.3 9.0 9.0 9.0 9.0 18.0 12.0 46.0 54.0 0.70 3.89 4.41
9 9 9 12 12 51 Ducted 8.1 8.1 8.1 10.8 10.8 9.5 9.5 9.5 12.7 12.7 12.0 46.0 54.0 0.70 3.89 4.41
9 9 12 12 12 54 Ducted 7.7 7.7 10.2 10.2 10.2 9.0 9.0 12.0 12.0 12.0 12.0 46.0 54.0 0.70 3.89 4.41
NOTES:
• Specifications are based on the following conditions.
– Power source of specifications: 230 V
– 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 15: 14,000 Btu/h, 18: 18,000 Btu/h, 24:
24,000 Btu/h
– 2 or more indoor units should be connected.
– Heating: Indoor temperature of 70 °FDB (21.1 °CDB) / 60 °FWB (15.6 °CWB), and outdoor
temperature of 47 °FDB (8.3 °CDB) / 43 °FWB (6.1 °CWB).
– Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
– The total ability of connected a indoor unit is from 34,000 Btu up to 54,000 Btu.
– Non-Ducted system combinations input are based on wall mount models. The input of combi-
nations including cassette models may be a little higher.
– Ducted system combinations capacities are based on slim duct units.
• Combination of 15+24 (14,000 Btu/h+24,000 Btu/h) of the indoor units is prohibited.
- 251 -
6-1. Combinations 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ

Fujitsu ASUH07LPAS Specifications
