Fujitsu ASUH07LPAS User Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
64 °FDB 70 °FDB 75 °FDB 80 °FDB 85 °FDB 90 °FDB
54 °FWB 60 °FWB 63 °FWB 67 °FWB 71 °FWB 73 °FWB
kBtu/h °FDB TC IP TC IP TC IP TC IP TC IP TC IP
48
14
37.6 1.71 42.5 1.74 44.8 1.76 48.0 1.78 51.3 1.80 52.9 1.81
23 37.6 1.70 42.5 1.73 44.8 1.75 48.0 1.77 51.3 1.79 52.9 1.80
32 37.6 1.69 42.5 1.72 44.8 1.74 48.0 1.76 51.3 1.78 52.9 1.79
41 37.6 1.89 42.5 1.92 44.8 1.94 48.0 1.96 51.3 1.98 52.9 1.99
50 37.6 2.08 42.5 2.12 44.8 2.13 48.0 2.16 51.3 2.18 52.9 2.19
59 37.6 2.86 42.5 2.91 44.8 2.94 48.0 2.97 51.3 3.00 52.9 3.02
67 37.6 3.65 42.5 3.71 44.8 3.74 48.0 3.78 51.3 3.82 52.9 3.85
77 37.6 4.02 42.5 4.09 44.8 4.12 48.0 4.17 51.3 4.21 52.9 4.24
87 37.6 4.39 42.5 4.46 44.8 4.50 48.0 4.55 51.3 4.60 52.9 4.63
95 37.6 4.68 42.5 4.77 44.8 4.81 48.0 4.86 51.3 4.92 52.9 4.94
104 32.7 4.35 37.0 4.43 39.0 4.46 41.8 4.51 44.6 4.56 46.0 4.59
115 27.8 4.01 31.5 4.08 33.2 4.12 35.5 4.16 38.0 4.21 39.1 4.23
47
14
37.6 1.71 42.5 1.74 44.8 1.76 48.0 1.78 51.3 1.80 52.9 1.81
23 37.6 1.70 42.5 1.73 44.8 1.75 48.0 1.77 51.3 1.79 52.9 1.80
32 37.6 1.69 42.5 1.72 44.8 1.74 48.0 1.76 51.3 1.78 52.9 1.79
41 37.6 1.89 42.5 1.92 44.8 1.94 48.0 1.96 51.3 1.98 52.9 1.99
50 37.6 2.08 42.5 2.12 44.8 2.13 48.0 2.16 51.3 2.18 52.9 2.19
59 37.6 2.86 42.5 2.91 44.8 2.94 48.0 2.97 51.3 3.00 52.9 3.02
67 37.6 3.65 42.5 3.71 44.8 3.74 48.0 3.78 51.3 3.82 52.9 3.85
77 37.6 4.02 42.5 4.09 44.8 4.12 48.0 4.17 51.3 4.21 52.9 4.24
87 37.6 4.39 42.5 4.46 44.8 4.50 48.0 4.55 51.3 4.60 52.9 4.63
95 37.6 4.68 42.5 4.77 44.8 4.81 48.0 4.86 51.3 4.92 52.9 4.94
104 32.7 4.35 37.0 4.43 39.0 4.46 41.8 4.51 44.6 4.56 46.0 4.59
115 27.8 4.01 31.5 4.08 33.2 4.12 35.5 4.16 38.0 4.21 39.1 4.23
46
14
37.6 1.71 42.5 1.74 44.8 1.76 48.0 1.78 51.3 1.80 52.9 1.81
23 37.6 1.70 42.5 1.73 44.8 1.75 48.0 1.77 51.3 1.79 52.9 1.80
32 37.6 1.69 42.5 1.72 44.8 1.74 48.0 1.76 51.3 1.78 52.9 1.79
41 37.6 1.89 42.5 1.92 44.8 1.94 48.0 1.96 51.3 1.98 52.9 1.99
50 37.6 2.08 42.5 2.12 44.8 2.13 48.0 2.16 51.3 2.18 52.9 2.19
59 37.6 2.86 42.5 2.91 44.8 2.94 48.0 2.97 51.3 3.00 52.9 3.02
67 37.6 3.65 42.5 3.71 44.8 3.74 48.0 3.78 51.3 3.82 52.9 3.85
77 37.6 4.02 42.5 4.09 44.8 4.12 48.0 4.17 51.3 4.21 52.9 4.24
87 37.6 4.39 42.5 4.46 44.8 4.50 48.0 4.55 51.3 4.60 52.9 4.63
95 37.6 4.68 42.5 4.77 44.8 4.81 48.0 4.86 51.3 4.92 52.9 4.94
104 32.7 4.35 37.0 4.43 39.0 4.46 41.8 4.51 44.6 4.56 46.0 4.59
115 27.8 4.01 31.5 4.08 33.2 4.12 35.5 4.16 38.0 4.21 39.1 4.23
45
14
37.6 1.71 42.5 1.74 44.8 1.76 48.0 1.78 51.3 1.80 52.9 1.81
23 37.6 1.70 42.5 1.73 44.8 1.75 48.0 1.77 51.3 1.79 52.9 1.80
32 37.6 1.69 42.5 1.72 44.8 1.74 48.0 1.76 51.3 1.78 52.9 1.79
41 37.6 1.89 42.5 1.92 44.8 1.94 48.0 1.96 51.3 1.98 52.9 1.99
50 37.6 2.08 42.5 2.12 44.8 2.13 48.0 2.16 51.3 2.18 52.9 2.19
59 37.6 2.86 42.5 2.91 44.8 2.94 48.0 2.97 51.3 3.00 52.9 3.02
67 37.6 3.65 42.5 3.71 44.8 3.74 48.0 3.78 51.3 3.82 52.9 3.85
77 37.6 4.02 42.5 4.09 44.8 4.12 48.0 4.17 51.3 4.21 52.9 4.24
87 37.6 4.39 42.5 4.46 44.8 4.50 48.0 4.55 51.3 4.60 52.9 4.63
95 37.6 4.68 42.5 4.77 44.8 4.81 48.0 4.86 51.3 4.92 52.9 4.94
104 32.7 4.35 37.0 4.43 39.0 4.46 41.8 4.51 44.6 4.56 46.0 4.59
115 27.8 4.01 31.5 4.08 33.2 4.12 35.5 4.16 38.0 4.21 39.1 4.23
44
14
36.8 1.68 41.6 1.71 43.8 1.72 46.9 1.74 50.2 1.76 51.7 1.77
23 36.8 1.67 41.6 1.70 43.8 1.71 46.9 1.73 50.2 1.75 51.7 1.76
32 36.8 1.66 41.6 1.69 43.8 1.70 46.9 1.72 50.2 1.74 51.7 1.75
41 36.8 1.85 41.6 1.88 43.8 1.90 46.9 1.92 50.2 1.94 51.7 1.95
50 36.8 2.04 41.6 2.07 43.8 2.09 46.9 2.11 50.2 2.14 51.7 2.15
59 36.8 2.81 41.6 2.85 43.8 2.88 46.9 2.91 50.2 2.94 51.7 2.96
67 36.8 3.57 41.6 3.64 43.8 3.67 46.9 3.71 50.2 3.75 51.7 3.77
77 36.8 3.94 41.6 4.01 43.8 4.04 46.9 4.08 50.2 4.13 51.7 4.15
87 36.8 4.30 41.6 4.38 43.8 4.41 46.9 4.46 50.2 4.51 51.7 4.54
95 36.8 4.59 41.6 4.67 43.8 4.71 46.9 4.76 50.2 4.82 51.7 4.84
104 32.0 4.26 36.2 4.34 38.1 4.37 40.8 4.42 43.6 4.47 45.0 4.50
115 27.2 3.93 30.8 4.00 32.4 4.04 34.7 4.08 37.1 4.13 38.3 4.15
43
14
36.0 1.62 40.6 1.65 42.8 1.66 45.9 1.68 49.0 1.70 50.5 1.71
23 36.0 1.61 40.6 1.64 42.8 1.65 45.9 1.67 49.0 1.69 50.5 1.70
32 36.0 1.60 40.6 1.63 42.8 1.64 45.9 1.66 49.0 1.68 50.5 1.69
41 36.0 1.79 40.6 1.82 42.8 1.83 45.9 1.85 49.0 1.87 50.5 1.88
50 36.0 1.97 40.6 2.00 42.8 2.02 45.9 2.04 49.0 2.07 50.5 2.08
59 36.0 2.71 40.6 2.76 42.8 2.78 45.9 2.81 49.0 2.84 50.5 2.86
67 36.0 3.45 40.6 3.51 42.8 3.54 45.9 3.58 49.0 3.62 50.5 3.64
77 36.0 3.80 40.6 3.87 42.8 3.90 45.9 3.95 49.0 3.99 50.5 4.01
87 36.0 4.15 40.6 4.23 42.8 4.26 45.9 4.31 49.0 4.36 50.5 4.38
95 36.0 4.44 40.6 4.51 42.8 4.55 45.9 4.60 49.0 4.65 50.5 4.68
104 31.3 4.12 35.3 4.19 37.3 4.23 39.9 4.27 42.7 4.32 44.0 4.34
115 26.6 3.80 30.1 3.87 31.7 3.90 33.9 3.94 36.3 3.99 37.4 4.01
42
14
35.1 1.56 39.7 1.59 41.8 1.60 44.8 1.62 47.9 1.64 49.4 1.65
23 35.1 1.56 39.7 1.58 41.8 1.60 44.8 1.61 47.9 1.63 49.4 1.64
32 35.1 1.55 39.7 1.57 41.8 1.59 44.8 1.60 47.9 1.62 49.4 1.63
41 35.1 1.72 39.7 1.75 41.8 1.77 44.8 1.79 47.9 1.81 49.4 1.82
50 35.1 1.90 39.7 1.93 41.8 1.95 44.8 1.97 47.9 1.99 49.4 2.01
59 35.1 2.62 39.7 2.66 41.8 2.68 44.8 2.71 47.9 2.74 49.4 2.76
67 35.1 3.33 39.7 3.39 41.8 3.42 44.8 3.46 47.9 3.50 49.4 3.51
77 35.1 3.67 39.7 3.74 41.8 3.77 44.8 3.81 47.9 3.85 49.4 3.87
87 35.1 4.01 39.7 4.08 41.8 4.11 44.8 4.16 47.9 4.21 49.4 4.23
95 35.1 4.28 39.7 4.36 41.8 4.39 44.8 4.44 47.9 4.49 49.4 4.52
104 30.6 3.97 34.5 4.04 36.4 4.08 39.0 4.12 41.7 4.17 42.9 4.19
115 26.0 3.67 29.4 3.73 31.0 3.76 33.1 3.80 35.4 3.85 36.5 3.87
- 253 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ

Fujitsu ASUH07LPAS Specifications

General

Brand	Fujitsu
Model	ASUH07LPAS
Category	Air Conditioner
Language	English
