 Unit: kW, °C
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW).
• The data is based on the following conditions:
Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: ASU7RLF1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
-5.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
0.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
5.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
10.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
15.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
20.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
25.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
30.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
35.0 1.72 1.21 1.95 1.38 2.05 1.58 2.20 1.78 2.35 1.95 2.42 2.23
40.0 1.50 0.91 1.69 1.04 1.79 1.20 1.91 1.35 2.04 1.47 2.11 1.69
46.1 1.27 0.66 1.44 0.75 1.52 0.87 1.63 0.97 1.74 1.07 1.79 1.22
MODEL: ASU9RLF1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
-5.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
0.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
5.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
10.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
15.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
20.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
25.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
30.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
35.0 2.21 1.55 2.49 1.76 2.63 2.03 2.81 2.28 3.01 2.49 3.10 2.86
40.0 1.92 1.17 2.17 1.33 2.29 1.53 2.45 1.72 2.62 1.89 2.70 2.16
46.1 1.63 0.85 1.84 0.96 1.94 1.11 2.08 1.25 2.22 1.36 2.29 1.56
MODEL: ASU12RLF1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
-5.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
0.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
5.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
10.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
15.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
20.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
25.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
30.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
35.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
40.0 2.56 1.46 2.89 1.67 3.05 1.92 3.26 2.16 3.49 2.36 3.60 2.70
46.1 2.18 1.06 2.46 1.21 2.59 1.39 2.78 1.56 2.97 1.71 3.06 1.96
MODEL: ASU15RLF1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
-5.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
0.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
5.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
10.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
15.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
20.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
25.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
30.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
35.0 3.68 2.39 4.15 2.72 4.38 3.13 4.69 3.52 5.01 3.85 5.17 4.41
40.0 3.20 1.80 3.61 2.06 3.81 2.37 4.08 2.66 4.36 2.91 4.50 3.33
46.1 2.72 1.31 3.07 1.49 3.24 1.71 3.47 1.92 3.71 2.10 3.82 2.41
- 269 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ
