4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: ASYG09KMCB
AFR
m
3
/h
750
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 2.91 1.46 2.84 1.49 2.77 1.52 2.70 1.55 2.63 1.58
-20 -21 3.21 1.58 3.14 1.61 3.06 1.65 2.98 1.68 2.91 1.71
-15 -16 3.52 1.67 3.43 1.70 3.35 1.74 3.27 1.77 3.18 1.81
-10 -11 4.03 1.78 3.94 1.82 3.84 1.86 3.74 1.89 3.65 1.93
-5 -7 4.37 1.87 4.26 1.91 4.16 1.95 4.06 1.99 3.95 2.03
0 -2 4.68 1.90 4.57 1.94 4.46 1.98 4.34 2.02 4.23 2.06
5 3 5.13 1.78 5.01 1.81 4.88 1.85 4.76 1.89 4.64 1.92
7 6 5.46 1.71 5.33 1.75 5.20 1.79 5.07 1.82 4.94 1.86
10 8 5.59 1.60 5.46 1.64 5.33 1.67 5.19 1.70 5.06 1.74
15 10 5.77 1.46 5.64 1.50 5.50 1.53 5.36 1.56 5.22 1.59
¢
M
odel: ASYG12KMCB
AFR
m
3
/h
750
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 3.10 1.44 3.03 1.47 2.96 1.50 2.88 1.53 2.81 1.56
-20 -21 3.40 1.56 3.32 1.59 3.23 1.62 3.15 1.66 3.07 1.69
-15 -16 3.77 1.70 3.68 1.74 3.59 1.77 3.50 1.81 3.41 1.84
-10 -11 4.25 1.81 4.14 1.84 4.04 1.88 3.94 1.92 3.84 1.96
-5 -7 4.73 1.95 4.62 1.99 4.51 2.03 4.40 2.07 4.28 2.11
0 -2 5.06 2.05 4.94 2.09 4.82 2.13 4.70 2.18 4.58 2.22
5 3 5.70 1.70 5.57 1.73 5.43 1.77 5.30 1.81 5.16 1.84
7 6 5.99 1.73 5.84 1.77 5.70 1.80 5.56 1.84 5.42 1.87
10 8 6.29 1.70 6.14 1.74 5.99 1.77 5.84 1.81 5.69 1.85
15 10 6.44 1.59 6.28 1.62 6.13 1.65 5.98 1.69 5.82 1.72
¢
M
odel: ASYG14KMCB
AFR
m
3
/h
770
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 3.55 2.26 3.46 2.30 3.38 2.35 3.30 2.40 3.21 2.44
-20 -21 3.97 2.27 3.87 2.31 3.78 2.36 3.69 2.41 3.59 2.45
-15 -16 4.42 2.28 4.32 2.32 4.21 2.37 4.10 2.42 4.00 2.47
-10 -11 5.15 2.28 5.03 2.33 4.91 2.37 4.79 2.42 4.66 2.47
-5 -7 5.64 2.27 5.50 2.32 5.37 2.37 5.23 2.42 5.10 2.46
0 -2 5.81 2.28 5.67 2.33 5.54 2.37 5.40 2.42 5.26 2.47
5 3 6.03 2.08 5.89 2.12 5.75 2.16 5.60 2.21 5.46 2.25
7 6 6.30 2.01 6.15 2.06 6.00 2.10 5.85 2.14 5.70 2.18
10 8 6.41 1.97 6.26 2.01 6.11 2.05 5.95 2.09 5.80 2.13
15 10 6.57 1.75 6.41 1.79 6.25 1.83 6.10 1.86 5.94 1.90
- 7 -
