10. Electrical characteristics
Model name AOYG09KMCBN AOYG12KMCBN AOYG14KMCBN
Power
supply
Voltage V 230~
Frequency Hz 50
Max operating current *1 A 9.5 11.0 11.5
Starting current A 3.7 4.7 7.1
Wiring
spec. *2
Circuit breaker current A 15
Power cable
mm
2
1.5
Connection
cable *3
Cross-sectional
area
mm
2
1.5
Limited wiring
length
m 21
*1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
*2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. As
the regulations of wire size and circuit breaker differ in each country or region, select appropriate de-
vices complied to the regional standard.
*3: Limit voltage drop to less than 2%. If voltage drop is 2% or more, increase cable conductor size.
- 47 -
10. Electrical characteristics
OUTDOOR UNIT
AOYG09-14KMCBN
OUTDOOR UNIT
AOYG09-14KMCBN
