1. Specifications
Type Inverter heat pump
Model name AOYG09KMCBN AOYG12KMCBN AOYG14KMCBN
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Starting current A 3.7 4.7 7.1
Fan
Airflow rate
Cooling
m
3
/h
2,020 2,020 2,020
Heating 1,440 1,620 1,620
Type × Q'ty Propeller fan × 1
Motor output W 49
Sound pressure level *
Cooling
dB (A)
48 49 49
Heating 43 47 47
Sound power level
Cooling
dB (A)
63 65 65
Heating 59 63 63
Heat exchanger type
Dimensions
(H × W × D)
mm
588 × 881 × 18.2
588 × 851 × 18.2
Fin pitch 1.3
Rows × Stages 1 × 28
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treat-
ment
PC fin
Compressor
Type × Q'ty DC rotary × 1
Motor output W 900
Refrigerant
Type (Global warming potential) R32 (675)
Charge g 850
Refrigerant oil
Type FW68S
Amount
cm
3
350
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
620 × 790 × 290
Gross 713 × 945 × 395
Weight
Net
kg
35
Gross 40
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8)
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
10 to 43
Heating -25 to 24
NOTES:
•
Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/ 19 °CWB, and outdoor temperature of 35 °CDB/ 24 °CWB.
– Heating: Indoor temperature of 20 °CDB/ 15 °CWB, and outdoor temperature of 7 °CDB/ 6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
- 34 -
1. Specifications
OUTDOOR UNIT
AOYG09-14KMCBN
OUTDOOR UNIT
AOYG09-14KMCBN
