2. Dimensions
2-1. Models: ASYG09KMCB, ASYG12KMCB, and ASYG14KMCB
Unit: mm
315
(840)
840 203
(268)
268
for pipe inlet Ø65
45 365 353 77
18
7
226
Outline of unit
- 3 -
