Fujitsu ASYG09KMCB Design & Technical Manual

5. Fan performance
5-1. Air velocity distributions
¢ Models: ASYG09KMCB and ASYG12KMCB
Measuring conditions
Fan speed Operation mode
HIGH FAN
Top view
Vertical airflow direction louver
: Up
Horizontal airflow direction louver: Center
2
1
0
1
2
Unit: m/s
(m)
(m)
0123456789
2.0
1.0 0.5
Top view
Vertical airflow direction louver
: Up
Horizontal airflow direction louver: Left & Right
3
2
1
0
1
2
3
Unit: m/s
(m)
(m)
0123456789
2.0
1.0
1.0
0.5
0.5
Side view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
3
2
1
0
Unit: m/s
(m)
(m)
0123456789
2.0
1.0
0.5
Side view
Vertical airflow direction louver
: Down
Horizontal airflow direction louver: Center
3
2
1
0
Unit: m/s
(m)
(m)
0123456789
2.0
1.0
0.5
- 8 -
5-1. Air velocity distributions 5. Fan performance
WALL MOUNTED ASYG09-14KMCB WALL MOUNTED ASYG09-14KMCB
