Heating
Combination of indoor unit
Rated capacity for each indoor unit (kB-
tu/h)
Total capacity
(kBtu/h)
Input power (kW)
COP
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SCOP
(kWh/
kWh)
Energy ef-
ficiency
class
1 2 3 4 5 1 2 3 4 5
7 24 — — — 31 2.40 8.40 — — — 3.5 10.8 12.4 0.7 2.97 3.34 3.64 8.9 3.9 A
9 24 — — — 33 3.00 8.40 — — — 3.5 11.4 13.2 0.7 3.15 3.58 3.62 9.0 3.9 A
12 24 — — — 36 4.00 8.00 — — — 3.5 12.0 14.0 0.7 3.34 3.82 3.59 9.0 4.0 A+
14 24 — — — 38 4.42 7.58 — — — 3.5 12.0 14.0 0.7 3.33 3.82 3.60 9.0 4.0 A+
18 18 — — — 36 6.00 6.00 — — — 3.5 12.0 14.0 0.7 3.34 3.82 3.59 9.0 4.0 A+
18 24 — — — 42 5.14 6.86 — — — 3.5 12.0 14.0 0.7 3.32 3.82 3.61 9.0 4.0 A+
24 24 — — — 48 6.00 6.00 — — — 3.5 12.0 14.0 0.7 3.31 3.82 3.62 9.0 4.0 A+
7 7 14 — — 28 2.40 2.40 4.80 - - 3.5 9.6 11.2 0.7 2.45 2.98 3.92 8.8 4.0 A+
7 7 18 — — 32 2.40 2.40 6.00 - - 3.5 10.8 12.8 0.7 2.80 3.46 3.86 9.0 4.0 A+
7 7 24 — — 38 2.21 2.21 7.58 - - 3.5 12.0 14.0 0.7 3.14 3.82 3.82 9.0 4.0 A+
7 9 12 — — 28 2.40 3.00 4.20 - - 3.5 9.6 11.2 0.7 2.45 2.98 3.92 8.8 4.0 A+
7 9 14 — — 30 2.40 3.00 4.80 - - 3.5 10.2 12.0 0.7 2.63 3.22 3.88 8.9 4.0 A+
7 9 18 — — 34 2.40 3.00 6.00 - - 3.5 11.4 13.6 0.7 2.97 3.70 3.84 9.0 4.0 A+
7 9 24 — — 40 2.10 2.70 7.20 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
7 12 12 — — 31 2.40 4.20 4.20 - - 3.5 10.8 12.4 0.7 2.79 3.34 3.87 8.9 4.0 A+
7 12 14 — — 33 2.40 4.20 4.80 - - 3.5 11.4 13.2 0.7 2.96 3.58 3.85 9.0 4.0 A+
7 12 18 — — 37 2.27 3.89 5.84 - - 3.5 12.0 14.0 0.7 3.14 3.82 3.82 9.0 4.0 A+
7 12 24 — — 43 1.95 3.35 6.70 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
7 14 14 — — 35 2.40 4.80 4.80 - - 3.5 12.0 14.0 0.7 3.14 3.82 3.82 9.0 4.0 A+
7 14 18 — — 39 2.15 4.31 5.54 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
7 14 24 — — 45 1.87 3.73 6.40 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
7 18 18 — — 43 1.96 5.02 5.02 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
7 18 24 — — 49 1.71 4.41 5.88 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
9 9 9 — — 27 3.00 3.00 3.00 - - 3.5 9.0 10.8 0.7 2.29 2.86 3.93 8.8 4.0 A+
9 9 12 — — 30 3.00 3.00 4.20 - - 3.5 10.2 12.0 0.7 2.63 3.22 3.88 8.9 4.0 A+
9 9 14 — — 32 3.00 3.00 4.80 - - 3.5 10.8 12.8 0.7 2.80 3.46 3.86 9.0 4.0 A+
9 9 18 — — 36 3.00 3.00 6.00 - - 3.5 12.0 14.0 0.7 3.14 3.82 3.82 9.0 4.0 A+
9 9 24 — — 42 2.57 2.57 6.86 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
9 12 12 — — 33 3.00 4.20 4.20 - - 3.5 11.4 13.2 0.7 2.96 3.58 3.85 9.0 4.0 A+
9 12 14 — — 35 3.00 4.20 4.80 - - 3.5 12.0 14.0 0.7 3.14 3.82 3.82 9.0 4.0 A+
9 12 18 — — 39 2.77 3.69 5.54 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
9 12 24 — — 45 2.40 3.20 6.40 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
9 14 14 — — 37 2.92 4.54 4.54 - - 3.5 12.0 14.0 0.7 3.14 3.82 3.82 9.0 4.0 A+
9 14 18 — — 41 2.63 4.10 5.27 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
9 14 24 — — 47 2.30 3.57 6.13 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
9 18 18 — — 45 2.40 4.80 4.80 - - 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
9 18 24 — — 51 2.12 4.24 5.64 - - 3.5 12.0 14.0 0.7 3.12 3.82 3.85 9.0 4.0 A+
12 12 12 — — 36 4.00 4.00 4.00 - - 3.5 12.0 14.0 0.7 3.14 3.82 3.82 9.0 4.0 A+
12 12 14 — — 38 3.79 3.79 4.42 - - 3.5 12.0 14.0 0.7 3.14 3.82 3.82 9.0 4.0 A+
12 12 18 — — 42 3.43 3.43 5.14 — — 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
12 12 24 — — 48 3.00 3.00 6.00 — — 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
12 14 14 — — 40 3.60 4.20 4.20 — — 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
12 14 18 — — 44 3.27 3.82 4.91 — — 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
12 14 24 — — 50 2.88 3.36 5.76 — — 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
12 18 18 — — 48 3.00 4.50 4.50 — — 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
12 18 24 — — 54 2.67 4.00 5.33 — — 3.5 12.0 14.0 0.7 3.12 3.82 3.85 9.0 4.0 A+
14 14 14 — — 42 4.00 4.00 4.00 — — 3.5 12.0 14.0 0.7 3.13 3.82 3.83 9.0 4.0 A+
14 14 18 — — 46 3.65 3.65 4.70 — — 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
14 14 24 — — 52 3.23 3.23 5.54 — — 3.5 12.0 14.0 0.7 3.12 3.82 3.85 9.0 4.0 A+
14 18 18 — — 50 3.36 4.32 4.32 — — 3.5 12.0 14.0 0.7 3.13 3.82 3.84 9.0 4.0 A+
18 18 18 — — 54 4.00 4.00 4.00 — — 3.5 12.0 14.0 0.7 3.12 3.82 3.85 9.0 4.0 A+
7 7 7 7 — 28 2.40 2.40 2.40 2.40 — 3.5 9.6 11.2 0.7 2.31 2.98 4.16 8.8 4.2 A+
7 7 7 9 — 30 2.40 2.40 2.40 3.00 — 3.5 10.2 12.0 0.7 2.47 3.22 4.13 8.9 4.2 A+
7 7 7 12 — 33 2.40 2.40 2.40 4.20 — 3.5 11.4 13.2 0.7 2.79 3.58 4.09 9.0 4.2 A+
7 7 7 14 — 35 2.40 2.40 2.40 4.80 — 3.5 12.0 14.0 0.7 2.95 3.82 4.07 9.0 4.2 A+
7 7 7 18 — 39 2.15 2.15 2.15 5.55 — 3.5 12.0 14.0 0.7 2.94 3.82 4.08 9.0 4.2 A+
7 7 7 24 — 45 1.87 1.87 1.87 6.39 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
7 7 9 9 — 32 2.40 2.40 3.00 3.00 — 3.5 10.8 12.8 0.7 2.64 3.46 4.09 9.0 4.2 A+
7 7 9 12 — 35 2.40 2.40 3.00 4.20 — 3.5 12.0 14.0 0.7 2.95 3.82 4.07 9.0 4.2 A+
7 7 9 14 — 37 2.27 2.27 2.92 4.54 — 3.5 12.0 14.0 0.7 2.95 3.82 4.07 9.0 4.2 A+
7 7 9 18 — 41 2.05 2.05 2.63 5.27 — 3.5 12.0 14.0 0.7 2.94 3.82 4.08 9.0 4.2 A+
7 7 9 24 — 47 1.79 1.79 2.30 6.12 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
7 7 12 12 — 38 2.21 2.21 3.79 3.79 — 3.5 12.0 14.0 0.7 2.94 3.82 4.08 9.0 4.2 A+
7 7 12 14 — 40 2.10 2.10 3.60 4.20 — 3.5 12.0 14.0 0.7 2.94 3.82 4.08 9.0 4.2 A+
7 7 12 18 — 44 1.91 1.91 3.27 4.91 — 3.5 12.0 14.0 0.7 2.93 3.82 4.09 9.0 4.2 A+
7 7 12 24 — 50 1.68 1.68 2.88 5.76 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
7 7 14 14 — 42 2.00 2.00 4.00 4.00 — 3.5 12.0 14.0 0.7 2.93 3.82 4.09 9.0 4.2 A+
7 7 14 18 — 46 1.83 1.83 3.65 4.69 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
7 7 14 24 — 52 1.62 1.62 3.23 5.53 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
7 7 18 18 — 50 1.68 1.68 4.32 4.32 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
7 9 9 9 — 34 2.40 3.00 3.00 3.00 — 3.5 11.4 13.6 0.7 2.80 3.70 4.07 9.0 4.2 A+
7 9 9 12 — 37 2.27 2.92 2.92 3.89 — 3.5 12.0 14.0 0.7 2.95 3.82 4.07 9.0 4.2 A+
7 9 9 14 — 39 2.15 2.77 2.77 4.31 — 3.5 12.0 14.0 0.7 2.94 3.82 4.08 9.0 4.2 A+
7 9 9 18 — 43 1.95 2.51 2.51 5.03 — 3.5 12.0 14.0 0.7 2.93 3.82 4.09 9.0 4.2 A+
7 9 9 24 — 49 1.71 2.20 2.20 5.89 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
7 9 12 12 — 40 2.10 2.70 3.60 3.60 — 3.5 12.0 14.0 0.7 2.94 3.82 4.08 9.0 4.2 A+
7 9 12 14 — 42 2.00 2.57 3.43 4.00 — 3.5 12.0 14.0 0.7 2.93 3.82 4.09 9.0 4.2 A+
7 9 12 18 — 46 1.83 2.35 3.13 4.69 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
7 9 12 24 — 52 1.62 2.08 2.77 5.53 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
7 9 14 14 — 44 1.91 2.45 3.82 3.82 — 3.5 12.0 14.0 0.7 2.93 3.82 4.09 9.0 4.2 A+
7 9 14 18 — 48 1.75 2.25 3.50 4.50 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
7 9 14 24 — 54 1.56 2.00 3.11 5.33 — 3.5 12.0 14.0 0.7 2.91 3.82 4.12 9.0 4.2 A+
7 9 18 18 — 52 1.62 2.08 4.15 4.15 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
7 12 12 12 — 43 1.95 3.35 3.35 3.35 — 3.5 12.0 14.0 0.7 2.93 3.82 4.09 9.0 4.2 A+
7 12 12 14 — 45 1.87 3.20 3.20 3.73 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
7 12 12 18 — 49 1.71 2.94 2.94 4.41 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
- 285 -
OUTDOOR UNIT AOYG36LBLA5
