Fujitsu ASYG09LMCA Design & Technical Manual

Combination of indoor unit
Rated capacity for each indoor unit (kB-
tu/h)
Total capacity
(kBtu/h)
Input power (kW)
COP
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SCOP
(kWh/
kWh)
Energy ef-
ficiency
class
1 2 3 4 5 1 2 3 4 5
7 12 14 14 — 47 1.80 3.06 3.57 3.57 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
7 12 14 18 — 51 1.65 2.82 3.29 4.24 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
7 14 14 14 — 49 1.71 3.43 3.43 3.43 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
7 14 14 18 — 53 1.58 3.17 3.17 4.08 — 3.5 12.0 14.0 0.7 2.91 3.82 4.12 9.0 4.2 A+
9 9 9 9 — 36 3.00 3.00 3.00 3.00 — 3.5 12.0 14.0 0.7 2.95 3.82 4.07 9.0 4.2 A+
9 9 9 12 — 39 2.77 2.77 2.77 3.69 — 3.5 12.0 14.0 0.7 2.94 3.82 4.08 9.0 4.2 A+
9 9 9 14 — 41 2.63 2.63 2.63 4.11 — 3.5 12.0 14.0 0.7 2.94 3.82 4.08 9.0 4.2 A+
9 9 9 18 — 45 2.40 2.40 2.40 4.80 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
9 9 9 24 — 51 2.12 2.12 2.12 5.64 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
9 9 12 12 — 42 2.57 2.57 3.43 3.43 — 3.5 12.0 14.0 0.7 2.93 3.82 4.09 9.0 4.2 A+
9 9 12 14 — 44 2.45 2.45 3.27 3.83 — 3.5 12.0 14.0 0.7 2.93 3.82 4.09 9.0 4.2 A+
9 9 12 18 — 48 2.25 2.25 3.00 4.50 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
9 9 12 24 — 54 2.00 2.00 2.67 5.33 — 3.5 12.0 14.0 0.7 2.91 3.82 4.12 9.0 4.2 A+
9 9 14 14 — 46 2.35 2.35 3.65 3.65 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
9 9 14 18 — 50 2.16 2.16 3.36 4.32 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
9 9 18 18 — 54 2.00 2.00 4.00 4.00 — 3.5 12.0 14.0 0.7 2.91 3.82 4.12 9.0 4.2 A+
9 12 12 12 — 45 2.40 3.20 3.20 3.20 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
9 12 12 14 — 47 2.30 3.06 3.06 3.58 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
9 12 12 18 — 51 2.12 2.82 2.82 4.24 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
9 12 14 14 — 49 2.20 2.94 3.43 3.43 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
9 12 14 18 — 53 2.04 2.72 3.17 4.07 — 3.5 12.0 14.0 0.7 2.91 3.82 4.12 9.0 4.2 A+
9 14 14 14 — 51 2.13 3.29 3.29 3.29 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
12 12 12 12 — 48 3.00 3.00 3.00 3.00 — 3.5 12.0 14.0 0.7 2.93 3.82 4.10 9.0 4.2 A+
12 12 12 14 — 50 2.88 2.88 2.88 3.36 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
12 12 12 18 — 54 2.67 2.67 2.67 3.99 — 3.5 12.0 14.0 0.7 2.91 3.82 4.12 9.0 4.2 A+
12 12 14 14 — 52 2.77 2.77 3.23 3.23 — 3.5 12.0 14.0 0.7 2.92 3.82 4.11 9.0 4.2 A+
12 14 14 14 — 54 2.67 3.11 3.11 3.11 — 3.5 12.0 14.0 0.7 2.91 3.82 4.12 9.0 4.2 A+
7 7 7 7 7 35 2.40 2.40 2.40 2.40 2.40 3.5 12.0 14.0 0.7 2.79 3.82 4.30 9.0 4.4 A+
7 7 7 7 9 37 2.27 2.27 2.27 2.27 2.92 3.5 12.0 14.0 0.7 2.79 3.82 4.30 9.0 4.4 A+
7 7 7 7 12 40 2.10 2.10 2.10 2.10 3.60 3.5 12.0 14.0 0.7 2.78 3.82 4.31 9.0 4.4 A+
7 7 7 7 14 42 2.00 2.00 2.00 2.00 4.00 3.5 12.0 14.0 0.7 2.78 3.82 4.32 9.0 4.4 A+
7 7 7 7 18 46 1.83 1.83 1.83 1.83 4.68 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
7 7 7 7 24 52 1.62 1.62 1.62 1.62 5.52 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 7 7 9 9 39 2.15 2.15 2.15 2.77 2.77 3.5 12.0 14.0 0.7 2.78 3.82 4.31 9.0 4.4 A+
7 7 7 9 12 42 2.00 2.00 2.00 2.57 3.43 3.5 12.0 14.0 0.7 2.78 3.82 4.32 9.0 4.4 A+
7 7 7 9 14 44 1.91 1.91 1.91 2.45 3.82 3.5 12.0 14.0 0.7 2.78 3.82 4.32 9.0 4.4 A+
7 7 7 9 18 48 1.75 1.75 1.75 2.25 4.50 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
7 7 7 9 24 54 1.56 1.56 1.56 2.00 5.32 3.5 12.0 14.0 0.7 2.76 3.82 4.35 9.0 4.4 A+
7 7 7 12 12 45 1.87 1.87 1.87 3.20 3.20 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
7 7 7 12 14 47 1.79 1.79 1.79 3.06 3.57 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
7 7 7 12 18 51 1.65 1.65 1.65 2.82 4.23 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 7 7 14 14 49 1.71 1.71 1.71 3.43 3.43 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 7 7 14 18 53 1.58 1.58 1.58 3.17 4.09 3.5 12.0 14.0 0.7 2.76 3.82 4.35 9.0 4.4 A+
7 7 9 9 9 41 2.05 2.05 2.63 2.63 2.63 3.5 12.0 14.0 0.7 2.78 3.82 4.31 9.0 4.4 A+
7 7 9 9 12 44 1.91 1.91 2.45 2.45 3.28 3.5 12.0 14.0 0.7 2.78 3.82 4.32 9.0 4.4 A+
7 7 9 9 14 46 1.83 1.83 2.35 2.35 3.64 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
7 7 9 9 18 50 1.68 1.68 2.16 2.16 4.32 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 7 9 12 12 47 1.79 1.79 2.30 3.06 3.06 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
7 7 9 12 14 49 1.71 1.71 2.20 2.94 3.44 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 7 9 12 18 53 1.58 1.58 2.04 2.72 4.08 3.5 12.0 14.0 0.7 2.76 3.82 4.35 9.0 4.4 A+
7 7 9 14 14 51 1.65 1.65 2.12 3.29 3.29 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 7 12 12 12 50 1.68 1.68 2.88 2.88 2.88 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 7 12 12 14 52 1.62 1.62 2.77 2.77 3.22 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 7 12 14 14 54 1.56 1.56 2.66 3.11 3.11 3.5 12.0 14.0 0.7 2.76 3.82 4.35 9.0 4.4 A+
7 9 9 9 9 43 1.96 2.51 2.51 2.51 2.51 3.5 12.0 14.0 0.7 2.78 3.82 4.32 9.0 4.4 A+
7 9 9 9 12 46 1.83 2.35 2.35 2.35 3.12 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
7 9 9 9 14 48 1.75 2.25 2.25 2.25 3.50 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
7 9 9 9 18 52 1.62 2.08 2.08 2.08 4.14 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 9 9 12 12 49 1.72 2.20 2.20 2.94 2.94 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 9 9 12 14 51 1.65 2.12 2.12 2.82 3.29 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 9 9 14 14 53 1.58 2.04 2.04 3.17 3.17 3.5 12.0 14.0 0.7 2.76 3.82 4.35 9.0 4.4 A+
7 9 12 12 12 52 1.61 2.08 2.77 2.77 2.77 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
7 9 12 12 14 54 1.56 2.00 2.67 2.67 3.10 3.5 12.0 14.0 0.7 2.76 3.82 4.35 9.0 4.4 A+
9 9 9 9 9 45 2.40 2.40 2.40 2.40 2.40 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
9 9 9 9 12 48 2.25 2.25 2.25 2.25 3.00 3.5 12.0 14.0 0.7 2.77 3.82 4.33 9.0 4.4 A+
9 9 9 9 14 50 2.16 2.16 2.16 2.16 3.36 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
9 9 9 9 18 54 2.00 2.00 2.00 2.00 4.00 3.5 12.0 14.0 0.7 2.76 3.82 4.35 9.0 4.4 A+
9 9 9 12 12 51 2.12 2.12 2.12 2.82 2.82 3.5 12.0 14.0 0.7 2.76 3.82 4.34 9.0 4.4 A+
9 9 9 12 14 53 2.04 2.04 2.04 2.72 3.16 3.5 12.0 14.0 0.7 2.76 3.82 4.35 9.0 4.4 A+
9 9 12 12 12 54 2.00 2.00 2.67 2.67 2.67 3.5 12.0 14.0 0.7 2.76 3.82 4.35 9.0 4.4 A+
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h, 18: 18,000 Btu/h, 24:
24,000 Btu/h
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230V
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is up to 54,000 Btu from 27,000 Btu.
DESIGN & TECHNICAL MANUAL
- 286 -
