Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
27
-10.0
7.56 1.01 8.54 1.03 9.01 1.03 9.64 1.05 10.31 1.06 10.63 1.06
-5.0 7.56 1.00 8.54 1.02 9.01 1.03 9.64 1.04 10.31 1.05 10.63 1.06
0.0 7.56 1.00 8.54 1.02 9.01 1.02 9.64 1.03 10.31 1.05 10.63 1.05
5.0 7.56 1.11 8.54 1.13 9.01 1.14 9.64 1.15 10.31 1.17 10.63 1.17
10.0 7.56 1.23 8.54 1.25 9.01 1.26 9.64 1.27 10.31 1.29 10.63 1.29
15.0 7.56 1.69 8.54 1.72 9.01 1.73 9.64 1.75 10.31 1.77 10.63 1.78
20.0 7.56 2.15 8.54 2.19 9.01 2.20 9.64 2.23 10.31 2.25 10.63 2.27
25.0 7.56 2.37 8.54 2.41 9.01 2.43 9.64 2.46 10.31 2.48 10.63 2.50
30.0 7.56 2.59 8.54 2.63 9.01 2.65 9.64 2.68 10.31 2.71 10.63 2.73
35.0 7.56 2.76 8.54 2.81 9.01 2.83 9.64 2.86 10.31 2.90 10.63 2.91
40.0 7.15 2.90 8.08 2.95 8.52 2.97 9.12 3.01 9.75 3.04 10.05 3.06
46.0 6.75 3.04 7.62 3.09 8.04 3.12 8.61 3.15 9.20 3.19 9.48 3.20
NOTES:
• TC: Total Capacity (kW), IP: Input Power (kW)
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230V
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is up to 54,000 Btu from 27,000 Btu.
• Input in the table are calculated based on the maximum indoor unit input combinations.
- 291 -
OUTDOOR UNIT
AOYG36LBLA5
