¢ Compact cassette type
MODEL: AUYG07LVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
-5.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
0.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
5.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
10.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
15.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
20.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
25.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
30.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
35.0 1.64 1.09 1.97 1.33 2.22 1.51 2.51 1.96 2.68 2.14 2.77 2.45
40.0 1.55 0.97 1.86 1.19 2.10 1.36 2.37 1.75 2.54 1.92 2.62 2.20
46.0 1.46 0.87 1.76 1.06 1.98 1.21 2.24 1.56 2.39 1.71 2.47 1.95
MODEL: AUYG09LVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
-5.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
0.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
5.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
10.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
15.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
20.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
25.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
30.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
35.0 2.10 1.38 2.52 1.68 2.85 1.92 3.22 2.48 3.44 2.71 3.55 3.11
40.0 1.99 1.23 2.39 1.51 2.70 1.72 3.05 2.22 3.26 2.43 3.36 2.78
46.0 1.87 1.10 2.25 1.34 2.55 1.53 2.87 1.97 3.07 2.16 3.17 2.47
MODEL: AUYG12LVLB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
-5.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
0.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
5.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
10.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
15.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
20.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
25.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
30.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
35.0 2.80 1.82 3.37 2.22 3.81 2.53 4.30 3.27 4.60 3.57 4.74 4.10
40.0 2.65 1.63 3.19 1.98 3.60 2.26 4.07 2.93 4.35 3.20 4.48 3.67
46.0 2.50 1.45 3.01 1.76 3.40 2.01 3.84 2.60 4.10 2.85 4.23 3.26
MODEL: AUYG14LVLB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
-5.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
0.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
5.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
10.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
15.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
20.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
25.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
30.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
35.0 3.26 2.01 3.93 2.45 4.44 2.79 5.01 3.61 5.36 3.95 5.52 4.52
40.0 3.09 1.80 3.72 2.19 4.20 2.50 4.74 3.23 5.07 3.53 5.22 4.05
46.0 2.91 1.60 3.51 1.95 3.96 2.22 4.47 2.87 4.78 3.14 4.93 3.60
DESIGN & TECHNICAL MANUAL
- 292 -
OUTDOOR UNIT AOYG36LBLA5
