Getting started
Removing monitor base
Before you can use a swivel arm or a wall bracket, you must remove the monitor base .
The display surface is susceptible to scratching!
1
1
1
1
► Switch off the mon itor and pull the power
plug out of the power socket.
► Lay the monitor on its face on a soft s urface.
► Remove the c over and d isconnect all cables.
► Remove the screws (1) on the rear
of the mon itor.
You can now mount a swivel arm or a wall
bracket in a ccord ance with VESA FPMPMI
using a hole spacing of 100 mm.
For instructions on how to mount the swivel arm or wall bracket, please see
the documen tation for the swivel arm or wall bracket.
Fujitsu Technology Solutions 15
