Getting s tarted
Connecting the device
Please observe the sa fety information in "Importa nt note s", Page 7.
CE conformance and optimum pict ure quality are guaranteed only if
you use the data cables supplied.
Switch off the monitor an d the computer.
Disconnect the power plug
from the computer.
Connecting cables to the monitor
The monitor ports are pr
otected by a cover.
The data cab les s upplie
d have two 1 5-pin D-SUB connectors or two 24-pin DVI
connectors for connec
tion to the monitor and to the computer.
Information on the c o
mputer connections and interfaces is contained in the
operating manual fo
r the computer.
34
5
67
89
1
2
9
1=Securi
ty slot for "Kensington Lock"
2 = Cover
3=Power
connector
4 = Display Port (DP) socket
5=DVI-
D socket (DVI)
6=D-SUBs
ocket (VGA)
7 = AUDIO-IN socket
8=USBIN
(Downstream)
9 = USB OUT (Upstream)
Remove the cover.
Select th e appropriate data cable for your computer.
16 Fujitsu Technology Solutions
