Operation
OSD menu functions
The OSD menu for analogue monitor operation is described below. During
digital operation some functions are not available, they are not needed because
of the digital transmission technology being used.
Adjusting the brightness and contrast
Call up the Brightness/Con
trast setting window
Brightness
Set the brightness of the display
With th is function you change the brightness of the background lighting.
Contrast
Set the contrast of the display
With this function you modify the contrast of bright colour tones.
Black level
Set the brightness of
the display
With this function y
ou modify the contrast of dark colour tones.
Auto level
Adjust the signal le
vel
With this function
you can autom atically set the contrast.
The function is executed with the
button.
If the contrast
is set too high, bright surfaces can no longer be distinguished from very
bright surf ace
s. If the contrast is set too low, the maximum brightn ess will not be a chieved.
Adjusting the picture size and position
Call the Image adjust setting window
Phase
Eliminate picture disturbance
With this function you fine-tune your monitor to eliminate picture disturbance.
Clock
Set synchr oni sation
With this function you adjust the picture width to eliminate v ertical picture
disturbances.
H-Position
Adjust the horizontal position
With this function you move the picture to the left or to the right.
V-Position
Adjust the vertical position
With this function you move the picture u p or down.
Expansion
Adjust the picture size
Full screen = s election of full screen mode
Keep aspect = maximum picture size withou t distortion (only for PC image)
Fujitsu Technology Solutions 25
