24 – English
Mainboard D3358
60
Fujitsu
COM1 Ports
COM1 port
PIN Signal
PIN
Signal
1
DCD 1
2
DSR 1
3
SIN 1
4
RTS 1
5
SOUT 1
6
CTS 1
7
DTR 1
8
RI 1
Pin 1
Pin 2
9 GND
TPM jumper
PIN Signal
1 RST_PCI_TPM_L
2 TPM_RESET_L
Per default the TPM jumper is stuffed. Removing the jumper will disable the TPM.
65
67
Table of Contents
Deutsch
7
Table of Contents
7
Übersicht über das Mainboard D3358
8
Handbuchkonventionen
10
Wichtige Hinweise
11
Allgemeine Informationen IM Zusammenhang mit Boards
11
Hardware-Spezifikationen
13
Blockdiagramm
15
Trusted Platform Module (TPM)
16
Grundlegende Sicherheitsfunktionen
16
Systemsicherheitsfunktionen
16
Auswahl der Korrekten Teile für das System
17
Betrachtungen zur CPU (Central Processor Unit)
17
Systemspeicherschnittstelle
17
BIOS POST-Codes (Port 80-Statusanzeigen)
18
Betrachtungen zur Stromversorgung
25
Installation des Boards
26
Intrusion-Anschluss (Intern)
26
PC2009 PSU-Anschluss (PC2009)
26
Kommunikationsanschlüsse
27
Frontpanel-Stiftleiste (Intern)
27
Anschlüsse für Speichergeräte
29
Anschlüsse für Systemüberwachung und -Verwaltung
29
Konfigurations-Jumper auf der Frontpanel-Stiftleiste
30
COM1-Anschluss
30
TPM-Jumper
30
Speicherinstallation
31
Vorgehen bei der Speicherinstallation
33
Prozessorinstallation
35
Installation von Prozessor und Kühlkörper
35
Montage des Kühlkörpers
37
Installation von Add-In-Karten
38
Anschließen von Externen Geräten
39
Externe Anschlüsse
39
Austauschen der Lithium-Batterie
40
BIOS-Update
41
Wann sollte ein BIOS-Update Durchgeführt werden
41
Wie Funktioniert ein BIOS-Update
41
BIOS Recovery
41
Glossar
42
English
43
Overview Mainboard D3358
44
Notational Conventions
46
Important Notes
47
Information about Boards
47
Hardware Specifications
49
Block Diagram
51
Basic Security Features
52
System Security Features
52
Trusted Platform Module (TPM)
52
Central Processor Unit (CPU) Considerations
53
Choose Proper Parts for Your System
53
System Memory Interface
53
BIOS POST-Codes (Port 80 Status Indicators)
54
Power Supply Considerations
61
Board Installation
62
Intrusion Connector (Internal)
62
PC2009 PSU Connector (PC2009)
62
Communication Connectors
63
Front Panel Pin Connector (Internal)
63
Configuration Jumper on Front Panel Pin Connector
65
Ports for Memory Devices
65
System Monitoring and Management Connectors
65
COM1 Ports
66
TPM Jumper
66
Installing the Memory
67
Memory Installation Procedure
69
Installing the Processor and Heatsink
71
Mounting Heat Sink
73
Installing Add-In Cards
74
Connecting External Devices
75
External Ports
75
Replacing Lithium Battery
76
BIOS Recovery
77
BIOS Update
77
How Does a BIOS Update Work
77
When Should a BIOS Update be Carried out
77
Glossary
78
