Fujitsu EVB JADE-­D - Page 16

Preliminary
16(45)
Prepared Document Number
Manfred Ortmann
Approved Checked Date Revision Storage
2009-10-05 PA 4.2 Mycable01
Following table shows the assignment from pins, signals and function of connector X201 I/O
signals side:
Pin Signal Function
1 VCC33 Power Supply 3.3 V for XXSvideo-D
2 VCC33 Power Supply 3.3 V for XXSvideo-D
3 VCC33 Power Supply 3.3 V for XXSvideo-D
4 VCC33 Power Supply 3.3 V for XXSvideo-D
5 GND Ground
6 GND Ground
7 INT_A0 Interrupt 0
8 I2C_SDA0 I2C 0 Data
9 INT_A1 Interrupt 1
10 I2C_SCL0 I2C 0 Clock
11 I2C_SDA1 I2C 1 Data
12 I2C_SCL1 I2C 1 Clock
13 INT_A3 Interrupt 3
14 SPI_DO1 SPI1 Master Data Output ( MOSI )
15 INT_A2 Interrupt 2
16 SPI_DI1 SPI1 Master Data Input ( MISO )
17 TSG_R_10 TCON Timing Signal 10
18 TSG_R_8 TCON Timing Signal 8
19 TSG_R_11 TCON Timing Signal 11
20 TSG_R_9 TCON Timing Signal 9
21 SPI_SCK1 SPI1 Master serial clock
22 UART_SOUT1 UART 1 serial output
23 SPI_SS1 SPI1 Master Slave Select
24 UART_SIN1 UART 1serial input
25 UART_SIN2 UART 2 serial input
26 UART_CTS0# UART 0 Clear to send
27 UART_SOUT2 UART 2 serial output
28 UART_SIN0 UART 0 serial input
29 ADCGND Ground for ADC signals
30 UART_RTS0# UART0 Request to send
31 AD_VRL1 Reference voltage "L" input
32 UART_SOUT0 UART 0 serial output
33 AD_VR1 Reference output
