9.2 Installation Specifications
9.2 Installation Specifications
The following table shows specifications related to scanner
installation.
Item Specification
Dimensions (mm)
(Without ADF paper
chute and Stacker)
Depth Width Height
168
(6.6in)
301 (11.8 in) 158
(6.2 in)
Installation Space
(mm)
700 (27.6in) x 400 (15.8in) x 380 (15.0in)
(D x W x H)
Weight (kg) 3.5kg (7.7 lb.)
Input
power
Voltage 100 to 120 VAC ±10% or
220 to 240 VAC ±10%
Phases Single-phase
Frequency 50 / 60 ± 3Hz
Power consumption 28 W or less
ATTENTION
Installation Space is the reference value of an
installation space required to read A4 manu-
script.
To Next Page
