74
6.2 R
eplacing th
e P
ad ASY
6.2
Replacing the P
a
d ASY
The f
ollo
wing sho
ws the proced
ure f
or repl
acing t
he P
ad ASY
.
1.
Remove an
y do
cuments on the A
DF paper chute
.
2.
Open the ADF
b
y pushin
g on the ADF button and
turning the ADF co
ver to the fr
ont.
CAUTION
Be careful, the ADF co
v
er ma
y close and
pinch y
our finger
.
ADF button
