2.1 Installing the Scanner
17
2
INSTALLATION OF A SCANNER
■
■■
■
Attaching the ADF paper chute
The following shows the procedure for attaching the ADF paper
chute.
1.
Hold the ADF paper chute and insert its tabs into
the counterpart holes on the scanner as shown
in the figure below.
The Side guide of the ADF paper chute has to face up.
ADF paper chute
tab
Side guide
