Checking and Resetting the Sheet Counters
■
Checking the Sheet Counters
The status of each consumable part can be viewed to
determine when to replace or clean the consumables.
The color of the counter gradually changes when a
replacement for a consumable is needed or when cleaning is
needed. The color of each counter changes as follows:
Brake roller counter/pick roller counter
These counters turn light yellow when the sheet count after the
consumable replacement reaches 95% of the value specified in
"Replacement Cycle of Consumables [Life Counter Alarm Setting]"
(page 176) in the Software Operation Panel, and turn yellow when the
sheet count reaches 100%.
Counter after cleaning
This counter turns yellow when the sheet count after cleaning
reaches the value specified in "Scanner Cleaning Cycle [Cleaning
Cycle]" (page 176) in the Software Operation Panel.
Ink counter
This counter turns yellow when the amount of remaining ink reaches
below 33% (only displayed when the imprinter is installed).
1 Start up the Software Operation Panel.
For details, refer to "8.1 Starting Up the Software Operation Panel"
(page 156).
2 From the listing on the left, select [Device Setting].
In this window, you can check the following items:
8.4 Settings Related to Sheet Counters
Item Description
Total Count (ADF) Total number of sheets scanned using
the ADF
Total Count (FB)
[fi-7700/fi-7700S]
Total number of sheets scanned using
the flatbed [fi-7700/fi-7700S]:
After cleaning Total number of sheets scanned after
cleaning
Brake Roller Number of sheets scanned after the
brake roller is replaced
To Next Page
