System expansions
Removing the board
Board,
► Open the casing (see "Opening the ca sing", Page 34).
1
2
► Loosen the screw (1).
► Remove the board from the riser card (2).
You must reinstall the rear slot cover plate due to cooling, fire protection and the EMC
regulations (regulations on electromagnetic compatibility) to be complied with.
► Reinstall the rear slot cover plate by inserting it in the installation slot from
the inside and securing it with the screw.
► Close the casing (see "
Closing the ca sing", Page 62).
60 Fujitsu
