Getting to Know Your Computer
7
LOCATING THE CONTROLS
AND CONNECTORS
Top and Front Components
The following is a brief description of your
LifeBook notebook’s top and front components.
(Figure 2-3)
Display Panel Latch
The display panel latch locks and releases the
display panel.
Display Panel
The display panel is a color LCD panel with back
lighting for the display of text and graphics.
Power/Suspend/Resume Button
The Power/Suspend/Resume button allows you
to suspend notebook activity without powering
off, resume your notebook from suspend mode,
and power on your notebook when it has been
shut down from Windows.
Status Indicator Panel
The Status Indicator Panel displays symbols that
correspond with a specific component of your
LifeBook notebook.
Volume Control
Use this button to increase or decrease the
volume while watching or listening to a DVD/CD
or TV.
Figure 2-3. LifeBook notebook with display open
Scroll Button
Keyboard
Stereo
Speaker
Remote Control
Infrared port*
Stereo
Speaker
Display
Panel
Latch
Display
Panel
Mode Button
LifeBook Application Panel
Status
Indicator
Panel
Power/
Suspend/
Resume
Button
Touchpad
Wireless
LAN Switch
TV/DVD/CD*
Button
Channel
Selector*
* Items marked with an asterisk (*) are
located on the TV Tuner model only.
Volume
Control
LB_Topaz 02 (05-18) 11/10/05, 8:31 AM7
