30
Rear Panel Features
For rear panel features related to the TV Tuner,
refer to Figure 4.
DC Power Jack
Used to connect the AC Adapter to the notebook.
External Monitor Port
Used to connect an external VGA monitor to run
the system display and the external source singly
or simultaneously.
Air Vents
The air vents allow the fan to draw in outside air
to cool the notebook.
DC Power Jack External Monitor Port Air Vents
Figure 4. Rear Panel Features
LB_Topaz 04 (23-54) 11/10/05, 8:33 AM30
