Getting to Know Your Computer
9
Left-Side Panel Components
The following is a brief description of your
LifeBook notebook’s left-side components.
(Figure 2-4)
Microphone Jack
The microphone jack allows you to connect an
external mono microphone.
Headphone Jack
The headphone jack allows you to connect
headphones or powered external speakers.
ExpressCard™ Slot
The ExpressCard™ Slot allows you to install an
ExpressCard™ module.
PC Card Slot
The PC Card Slot allows you to install a Type I or
Type II PC Card.
Figure 2-4. LifeBook notebook left-side panel
Microphone Jack
PC Card Slots
USB 2.0 Port
The USB port allows you to connect Universal
Serial Bus 2.0 or USB 1.1 devices. Note that there
are three additional USB 2.0 ports on the rear of
the system.
Memory Stick/SD Card Slot
The Memory Stick/SD card slot allows you to
install a flash memory card for data storage. This
architecture allows you to transfer data from a
variety of different digital devices, such as SD
card, Memory Stick or Memory Stick Pro.
IEEE 1394 (4-pin) Port
The 1394 port is used to connect between your
LifeBook notebook and a peripheral such as a
digital video camera.
Headphone Jack
ExpressCard™ Slot
1394 Jack
Memory Stick/SD Card Slot
USB Port
Eject Buttons
LB_Topaz 02 (05-18) 2/3/05, 2:26 PM9
