Working with the notebook
Removing a battery
► Prepare for removal, see chapter "Preparing to remo ve components", Page 68.
2
1
3
► Slide the release button in the direction of the arrow (1) and hold it in place.
► Slide the re lease button in d irection of the arrow (2).
► Remove the battery from the battery compartment (3).
Installin g a battery
2
1
► Position the battery at the edge.
► Insert the battery into th e battery compa rtment until it engag es positively (1).
► Slide the release button in the direction of the arrow (2).
► Complete the removal, see chapter "
Finishing component remo val", Page 73.
Fujitsu Technology Solutions 35
