90
- Device Ports
Device Ports
Your Fujitsu LifeBook Tablet PC and the optional Port Replicator come equipped with multiple ports to
which you can connect external devices including: disk drives, keyboards, printers, etc.
Internal LAN (RJ-45) Jack
The internal LAN (RJ-45) jack is used for a Gigabit (10Base-T/100Base-Tx/1000Base-T) Ethernet LAN
connection. You may need to configure your Tablet PC to work with your particular network. (Please refer
to your network administrator for information on your network configuration.) To connect the LAN cable
follow these easy steps:
1 Align the connector with the port
opening.
2 Push the connector into the port until it
is seated.
3 Plug the other end of the cable into a
LAN outlet.
Figure 37. Connecting the LAN
