Working with the notebook
Connecting the AC adapter to the Port Replicator
3
1
2
► Connect the AC cable to the AC adapter (1).
► Plug the AC cable into the power outlet (2).
► Connect the AC adapter ca ble to the DC
jack (DC IN) o f the P ort Replicator (3).
Power outlets will vary from country to country, see chapter "When
travel ling in other countries ", Page 13.
When the notebook is connected to a port replicator, the operating system creates
a hardware profile for the "Docked" mode. In this profile, for example, the monitor
which was last used for output is saved as a setting. This profile will be loaded as
soon as the notebook is connected to a Port Replicator of the same type.
Fujitsu 43
