Fujitsu MAP3147 - Self-Test Result Page (X10); Self-Test Result Parameter Data (Page 10, Code 0001-0014)

Parameter Data Formats
4 - 56 C141-E167
The values stored in the General usage parameter bytes represent data sent to the device server in a
previous LOG SELECT command. If a previous LOG SELECT command has not occurred, the
data is zero.
4.2.10 Self-test result page (X'10')
Bit
Byte
76543210
0 00010010
1 X‘00’ (Reserved)
2 Page Length (MSB)
3 Page Length (LSB)
All of the following parameters have this header.
Page Length will be defined based on the value of Parameter Pointer. (CDB 5-6)
4.2.10.1 Self-test result parameter data (Page 10, Code 0001-0014)
Bit
Byte
76543210
4
5
(MSB)
X'0001'-X'0014' (Parameter code)
(Self-Test Result Parameter) (LSB)
DU DS TSD ETC TMC LBIN LP6
00000000
7 X'10' (Parameter Length)
8 Self-Test Code 0 Self-Test Result Value
9 Self-Test Segment Number
10
11
(MSB)
Time Stamp
(LSB)
12 (MSB)
Address of First Failure
19 (LSB)
20 0 0 0 0 Sense Key
21 Additional Sense Code
22 Additional Sense Code Qualifier
23 X'xx' (Vendor-specific)
Refer the document "T10/99-179r5 Logical Unit Self-test".
~
~
~
~
~
~
