Command Specifications
3 - 14 C141-E167
Bit
Byte
76543210
0 Logical Block Address (MSB)
1 Logical Block Address
2 Logical Block Address
3 Logical Block Address (LSB)
4 Block Length (MSB)
5 Block Length
6 Block Length
7 Block Length (LSB)
Figure 3.6 READ CAPACITY data
3.1.4 CHANGE DEFINITION (40)
Bit
Byte
76543210
0 X‘40’
1 LUN 00000
20000000Save
3 0 SCSI Level
400000000
500000000
600000000
700000000
8 Parameter List Length
90000000Link
This command changes the IDD's SCSI level and the operation mode.
The INIT can know the SCSI level and operation mode that the IDD is currently using by the
INQUIRY command (Standard Inquiry Data and VPD Information - Operation Mode Page: Page
code X 'C0').
If the "Save" bit of CDB byte 2 specifies "1," the IDD saves the SCSI level and operation mode
specified in this command in the Boot-ROM (Flash ROM) when the command is executed.
If this bit specifies "0," the changes are not saved.
