Fujitsu MAP3147 - MODE SENSE Command (Group 0) Parameter Configuration

3.1 Control/Sense Commands
C141-E167 3 -
31
Header
Bit
Byte
76543210
0 Sense Data Length
1 X‘00’ (Media Type)
2 WP 0 0 DPOFUA 0 0 0 0
3 X‘00’ or X‘08’ (Block Descriptor Length)
Block Descriptor
Bit
Byte
76543210
0 Data Block Count (MSB)
1 Data Block Count
2 Data Block Count
3 Data Block Count (LSB)
4 X‘00’
5 Data Block Length (MSB)
6 Data Block Length
7 Data Block Length (LSB)
Page Descriptor
Bit
Byte
76543210
0 0 0 Page Code
1 Page Length
2
n
Figure 3.10 MODE SENSE command (Group 0) parameter configuration
~
~
~
~
~
~
Page
Header
Parameter Field
