2.1 Hardware Specifications
(*3) The seek time is as follows:
Seek time [ms]
Seek difference [4096 Cyl/div]
(*4) The start time is the time from power on or start command to when the HDDs are ready, and the stop
time is the time for disks to completely stop from power off or stop command.
(*5) This value indicates in idle mode. Power supply at nominal voltage ±1%. 25°C ambient.
(*6) The maximum data transfer rate may be restricted to the response speed of initiator and by
transmission characteristics. 1 MB/s = 1,000,000 bytes/s.
(*7) Refer to 1.1 (13).
(*8) The eye mask is as follows:
Parameter Unit 1.5Gbps 3.0Gbps
2×Z2 mVp-p 1,600 1,600
2×Z1 mVp-p 325 275
X1 UI 0.275 0.275
X2 UI 0.5 0.5
bsolute amplitude [V]
Normalized time [UI]
C141-E266
23
