Diagnostics and Maintenance
6.5 Packaging
When the products are packed, the following methods are recommended.
6.5.1 Bag packaging
Conductivity bag
Seal tape
1st folding
From
Connector
side
Product
2nd folding
1) 2)
3)
Figure 6.2 Bag packaging
(1) Put the product in the conductivity bag.
• The product shall be put in the bag from the connector side.
(2) Fold the bag, and then seal the bag with the seal.
76 C141-E266
