Installation Requirements
Table 4.2 Interface connector (SAS plug) signal allocation:CN1
Pin No. Signal Description
S1 GND GND for SAS Primary Port
S2 RP+ SAS Primary Port Receive (positive) signal
S3 RP- SAS Primary Port Receive (negative) signal
S4 GND GND for SAS Primary Port
S5 TP- SAS Primary Port Transmit (negative) signal
S6 TP+ SAS Primary Port Transmit (positive) signal
S7 GND GND for SAS Primary Port
S8 GND GND for SAS Secondary Port
S9 Rs+ SAS Secondary Port Receive (positive) signal
S10 Rs- SAS Secondary Port Receive (negative) signal
S11 GND GND for SAS Secondary Port
S12 Ts- SAS Secondary Port Transmit (negative) signal
S13 Ts+ SAS Secondary Port Transmit (positive) signal
S14 GND GND for SAS Secondary Port
P1 (*1) Reserved (not used) Not used
P2
(*1) Reserved (not used) Not used
P3
(*1) Reserved (not used) Not used
P4 GND GROUND
P5 GND GROUND
P6 GND GROUND
P7 +5V-Charge Pre-charge pin for +5V
P8 +5V +5V power supply input
P9 +5V +5V power supply input
P10 GND GROUND
P11 READY LED READY LED output
P12 GND GROUND
P13 +12V-Charge Pre-charge pin for +12V
P14 +12V +12V power supply input
P15 +12V +12V power supply input
(* 1) P1 to P3 are +3.3V power supply input and pre-charge signals, and not used on MBB2147RC and MBB2073RC.
50 C141-E266
