4.3 Connection Requirements
4.3.2 Interface connector
Figure 4.10 shows the SAS type interface connector (SAS plug) overview.
Table 4.2 lists the signal allocation of the SAS plug on the HDDs.
S1
S7
P1
P15
S14
S8
Top view
Bottom view
Top view
Bottom view
Figure 4.10 SAS plug connector overview
C141-E266 49
